Oursson JM4600/OR - Инструкция по эксплуатации - Страница 11

11

problem

Solutions

A lot of pulp in
the juice

•

With continued juicing and depending on the ingredients, juice may contain much pulp.

•

To reduce the pulp in the juice, disassemble the juice cup and remove the pulp more often.

•  If the filter or screw is damaged - it can affect the performance and quality of juice. It is recom

-

mended to replace them. The service life of each part depends upon the duration and the
method of using the device, and pressing ingredients.

•

If too much of the ingredients are loaded into the juice maker simultaneously, this can lead to
frequent stoppages and to a large number of pulp in the juice. Place ingredients slowly and in
small portions.

Extraneous
sounds when
the device is
working

•

Make sure that all parts are correctly assembled.

•

Do not turn the juice maker without ingredients or at least liquid in it. Empty working juice
maker may damage the pressure screw

•  Depending on the type or size of various ingredients different noises my occur.

•

Noise may occur when the juice maker is working on uneven or inclined surfaces. Lace it on a

flat stable surface.

Pulp is very wet

•

At the beginning of juicing, the pulp can be wet.

•

The recovered pulp can be wet if you are using stale ingredients

Cup vibration

•

A small vibration of juice cup is allowed during operation. It is not considered a malfunction

The device has
stopped working

•

Make sure the amount of fruit and vegetables is not too large and the motor is not overloaded.

•

Make sure all the large seeds were removed from the fruit.

•  Turn off the device and switch it on REV (Reverse) mode for 2-3 seconds. Turn on the device

again.

pRODUcT cERTIFIcATION

For information on product certification, see

http://www.oursson.com

 or ask seller for a copy.

Specifications

Model

JM4600

JM4700

Power consumption, W

max 150

max 150

Rated voltage

220-240 V~; 50-60 Hz

220-240 V~; 50-60 Hz

Protection class

I

I

Storage and transportation temperature requirements* -25 °C

to

 +35 °C

-25 °C

to

 +35 °C

Operation temperature requirements

+5 °C

to

 +35 °C

+5 °C

to

 +35 °C

Humidity requirements

15-75%

15-75%

Dimensions (H×W×L), mm

101x125x359

150х110х372

Weight, kg

1.6

2.2

*Products should be stored in dry, ventilated warehouses at temperatures below - 25°C.

Only a qualified specialist of an authorized service center OURSSON AG can repair the juice maker.
