YDP-151/YDP-323   èËÎÓÊÂÌËÂ

43

<Table 1>

MIDI Parameter Change table (SYSTEM)

Address (H)

Size (H)

Data (H)

Parameter

Description

Default value (H)

00 00 00

4

020C - 05F4(*1)

MASTER TUNE

-50 - +50[cent]

00 04 00 00

            01

1st bit 3 - 0

➝

bit 15 - 12

400

            02

2nd bit 3 - 0

➝

bit 11 - 8

            03

3rd bit 3 - 0

➝

bit 7 - 4

4th bit 3 - 0

➝

bit 3 - 0

            04

1

00 - 7F

MASTER VOLUME

0 - 127

7F

            7E

00

XG SYSTEM ON

00=XG sytem ON

            7F

00

RESET ALL PARAMETERS

00=ON (receive only)

TOTAL SIZE 07

*1: Values lower than 020CH select -50 cents. Values higher than 05F4H select +50 cents.

<Table 2>

MIDI Parameter Change table (EFFECT 1)

Refer to the “Effect MIDI Map” for a complete list of Reverb, Chorus and Variation type numbers.

Address (H)

Size (H)

Data (H)

Parameter

Description

Default value (H)

02 01 00

2

00-7F

REVERB TYPE MSB

Refer to Effect MIDI Map

01(=HALL1)

00-7F

REVERB TYPE LSB

00 : basic type

00

02 01 40

2

00-7F

VARIATION TYPE MSB

Refer to Effect MIDI Map

00(=Effect off)

00-7F

VARIATION TYPE LSB

00 : basic type

00

• “VARIATION” refers to the EFFECT on the panel.

<Table 3>

MIDI Parameter Change table (MULTI PART)

Address (H)

Size (H)

Data (H)

Parameter

Description

Default value (H)

08 nn 11

1

00 - 7F

DRY LEVEL

0 - 127

7F

nn = Part Number

• Effect MIDI Map

REVERB

MSB

LSB

ROOM

02H

10H

HALL 1

01H

10H

HALL 2

01H

11H

STAGE

03H

10H

OFF

00H

00H

EFFECT

MSB

LSB

CHORUS

42H

10H

PHASER

48H

10H

TREMOLO

46H

10H

ROTARY SP

47H

10H

OFF

00H

00H
