 6



 • The tool must be used only for its prescribed purpose. Any use other than

    those mentioned in this Manual will be considered a case of misuse. The user

    and not the manufacturer shall be liable for any damage or injury resulting from

    such cases of misuse.

 • To use this tool properly, you must observe the safety regulations, the assembly

    instructions and the operating instructions found in this Manual. All persons who

    use and service the machine have to be acquainted with this Manual and must

    be informed about its potential hazards. Children and frail people must not use

    this tool. Children should be supervised at all times if they are in the area in

    which the tool is being used. It is also imperative that you observe the accident

    prevention regulations in force in your area. The same applies for general rules

    of occupational health and safety.

 • The manufacturer shall not be liable for any changes made to the tool nor for

    any damage resulting from such changes.

 •  Power tools must not be used outdoors in rainy weather, or in moist environ-

    ment (after rain) or in close vicinity with easily flammable liquids and gases.

    The working place should be well lit.

EN

KNOW YOUR PRODUCT

OPERATION

MAINTENANCE

Before using the power tool, familiarize yourself with all the

operating features and safety requirements.

Use the tool and accessories only for the applications intended.

All other applications are expressly ruled out.

1. Mixing paddle

2. M14 tool connection shaft

3. Electronic regulator of rotation speed

4. Speed selector switch

5. Lock-on button

6. ON/OFF switch

7. Motor housing

 3. KNOW YOUR PRODUCT

 4. OPERATIOIN

This power tool is supplied from single-phase alternating current mains only. It is

double insulated according to EN 60745-1 and IEC 60745 and can be connected

to grounded or not grounded sockets.

This power tool is radio suppressed in compliance with EMC Directive.

This power tool is designed for:

- Operation in industry and household;

- Mixing low-viscosity emulsions and viscous materials, for example: paints,

  lacquer, adhesives, mortar, etc.;

- Operation with mixing paddles and accessories specified here or recommended

  by the manufacturer.

 5. MAINTENANCE

 7

P

RIOR TO INITIAL OPERATION



• Make sure the power supply voltage corresponds to the value indicated on the

  name plate with technical data of the tool.

• Always check the position of ON/OFF switch. The power tool must be connected

  and disconnected to the power supply socket only when this switch is in OFF

  position. If the plug is connected to a receptacle while the power switch is in the

  ON position, the power tool will start operating immediately, which could cause a

  serious accident.

• Make sure that the cord and the plug are in order. If the replacement of the supply

  cord is necessary, this has to be done by the manufacturer or his agent in order to

  avoid a safety hazard.

• Check the power tool and the mixing paddle for faults, unbalanced paddle and

  vibrations. Perform a trial test.

WARNING:

Always switch off and unplug the power tool prior to any adjustment,

servicing or maintenance or in case of mains drop-out.

SWITCHING ON - SWITCHING OFF

Brief activation

Switching on: press ON/OFF switch (6).

Switching off: release ON/OFF switch (6).

Continuous use



Switching on: press ON/OFF switch (6) and in pressed position lock it by button (5).

Switching off: press ON/OFF switch (6) once and release it immediately.

ELECTRONIC RPM CONTROL

Light pressure on ON/OFF switch (6) results in low rotation speed, further pressing

the switch results in smooth increase of the rpm to maximum upon reaching the

extreme position.

MECHANICAL SPEED REGULATOR

Two RPM ranges can be pre - selected with the speed selector switch (4):

Gear 1



180-400 /min

Gear 2  300-700 /min

The necessary speed depends on the type of the material mixed and it is

recommended to verify it by a practical test.

GENERAL INSPECTION



Regularly inspect all fasteners and ensure they are properly tightened.

Should any of the screws be loose, retighten it immediately to avoid hazards.

If the replacement of the supply cord is necessary, this has to be done by the

manufacturer or his agent in order to avoid a safety hazard.

CLEANING



For safe operation always keep the machine and its ventilation slots clean.

Regularly check to see if any dust or foreign matter has entered the ventilation

slots and the grills around the switches. Use a soft brush and/ or air jet to remove

any accumulated dust.
