Electrical safety

This tool is double insulated; therefore no earth

wire is required. Always check that the power

supply corresponds to the voltage on the rating

plate.

•  If the supply cord is damaged, it must be replaced by the

manufacturer or an authorised STANLEY Service Centre

in order to avoid a hazard.

Features

This tool includes some or all of the following features.

1.  Variable speed switch

2.  Lock-on button

3.  Forward/reverse button

4.  Drilling mode selector

5.  Chuck
The following accessories may not be available with your

unit
6.  Depth stop

7  Side handle (STDH5510, STDH6513 only)

Assembly

Warning!

 Before assembly, make sure that the tool is

switched off and unplugged

Fitting the side handle and depth stop (fig. A, B)

•  Turn the grip counter clockwise until you can slide the

side handle (7) onto the front of the tool as shown

(fig. A).

•  Rotate the side handle into the desired position.
•  Insert the depth stop (6) into the mounding hole as

shown (Fig.B)

•  Set the drilling depth as described below.
•  Tighten the side handle by tuming the grip clockwise.

Fitting a drill bit (Fig.C)

•  Open the chuck by turning the sleeve (5) counter

clockwise.

•  Insert the bit shaft (9) into the chuck ( drill bit not

included)

•  Insert the chuck key (10) into each hole (8) in the side of

the chuck and turn clockwise until it is tight.

Removing and refitting the chuck (Fig.D)

•  Open the chuck as far as possible.

•  Remove the chuck retaining screw, located in the chuck,

by turning it clockwise using a screwdriver.

•  Tighten an Allen key. Remove the chuck by turning it

counter clockwise.

•  To refit the chuck, screw it onto the spindle and secure it

with the chuck retaining screw.

Residual risks

Additional residual risks may arise when using the tool which

may not be included in the enclosed safety warnings. These

risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations

and the implementation of safety devices, certain residual

risks cannot be avoided. These include:

•  Injuries caused by touching any rotating/moving parts.
•  Injuries caused when changing any parts, blades or

accessories.

•  Injuries caused by prolonged use of a tool. When using

any tool for prolonged periods make sure you take

regular breaks.

•  Impairment of hearing.
•  Health hazards caused by breathing dust developed

when using your tool (example:- working with wood,

especially oak, beech and MDF).

USE

Warning!

 Let the tool work at its own pace. Do not

overload.

Warning!

 Before drilling into walls , floors or

ceilings, check for the location of wiring and pipes.

Selecting the direction of rotation (fig.E)

For drilling and for tightening screws, use forward

(clockwise) rotation. For loosening screws or removing a

jammed drill bit, use reverse (counter clockwise) rotation.

•  To select  forward rotation, push the forward/ reverse

button (3) to the left position.

•  To select reverse rotation, push the forward /reverse

button to the right. Warning! Never change the direction

of rotation while the motor is running.

Selecting the drilling mode

•  For drilling in masonry, set the drilling mode selector (4)

to the    position.

•  For drilling in other materials and for screwdriving, set

the drilling mode selector to the     position.
