7

(Original instructions)

ENGLISH

Assembly

Warning!

Before assembly, remove the battery from the

tool.

Fitting and removing the battery (FIG. B)

•  To fit the battery (7), line it up with the receptacle on the

tool. Slide the battery into the receptacle and push until

the battery snaps into place.

•  To remove the battery, push the release button (13)

while at the same time pulling the battery out of the

receptacle.

Fitting and removing a drill bit or screwdriver bit

This tool is fitted with a keyless chuck to allow for an easy

exchange of bits.

•  Lock the tool by setting the forward/reverse slider (2) to

the centre position.

•  Open the chuck by turning it (4) with one hand while

holding the tool with the other.

•  Insert the bit shaft into the chuck.

•  Firmly tighten the chuck by turning it (4) with one hand

while holding the tool with the other.

This tool is supplied with a double-ended screwdriver bit in

the bit holder (6).

•  To remove the screwdriver bit from the bit holder, lift the

bit from the recess.

•  To store the screwdriver bit, firmly push it into the holder.

Use

Warning!

  Let the tool work at its own pace. Do not

overload.

Warning!

  Before drilling into walls, floors or ceilings, check

for the location of wiring and pipes.

Charging the battery (FIG.A)

The battery needs to be charged before first use and

whenever it fails to produce sufficient power on jobs that

were easily done before. The battery may become warm

while charging; this is normal and does not indicate a

problem.

Warning!

 Do not charge the battery at ambient tempera-

tures below 10 °C or above 40 °C. Recommended charging

temperature: approx. 24 °C.

Note:

The charger will not charge a battery if the cell

temperature is below approximately 0 °C or above 40

°C. The battery should be left in the charger and the

charger will begin to charge automatically when the cell

temperature warms up or cools down.

•  To charge the battery (7), insert it into the charger (11).

The battery will only fit into the charger in one way. Do not

force. Be sure that the battery is fully seated in the

charger.

•  Plug in the charger and switch on at the mains.

The charging indicator (12) will flash green (slowly).

The charge is complete when the charging indicator (12)

lights green continuously. The charger and the battery can be

left connected indefinitely with the LED illuminated. The LED

will change to flashing green (charging) state as the charger

occasionally tops up the battery charge. The charging

indicator (12) will be lit as long as the battery is connected to

the plugged-in charger.

•  Charge discharged batteries within 1 week. Battery life

will be greatly diminished if stored in a discharged state.

Leaving the battery in the charger

The charger and battery pack can be left connected with the

LED glowing indefinitely. The charger will keep the battery

pack fresh and fully charged.

Charger diagnostics

If the charger detects a weak or damaged battery, the

charging indicator (12) will flash red at a fast rate. Proceed as

follows:

•  Re-insert the battery (7).

•  If the charging indicators continues flashing red at a fast

rate, use a different battery to determine if the charging

process works properly.

•  If the replaced battery charges correctly, the original

battery is defective and should be returned to a service

centre for recycling.

•  If the new battery gives the same indication as the

original battery, take the charger to be tested at an

authorised services centre.

Note: It may take as long as 60 minutes to determine that

the battery is defective. If the battery is too hot or too

cold, the LED will alternately blink red, fast and slow, one

flash at each speed and repeat.

Selecting the direction of rotation (FIG. C)

For drilling and for tightening screws, use forward (clockwise)

rotation. For loosening screws or removing a jammed drill bit,

use reverse (counterclockwise) rotation.

•  To select forward rotation, push the forward/reverse slider

(2) to the left.

•  To select reverse rotation, push the forward/reverse slider

to the right.

•  To lock the tool, set the forward/reverse slider into the

centre position
