– take the chuck key and insert it  in one of

the three holes in the body of the chuck.

Turn the chuck key clock-wise to tighten the

jaws. Then remove the chuck key. To

ensure that the drill bit is tightly fasten, place

the chuck key into a different hole and turn

clockwise again to tighten the jaws;
– to remove the drill bit insert the chuck

key in one of the three holes in the body

of the chuck. Rotate the chuck key

counter-clockwise to open the jaws.

Remove the drill bit.

When drilling the hole be sure to secure the work piece firmly. Use only sharp drill

bits. When drilling holes be careful to apply less force at the end, when the drill bit

comes through the surface of the work piece.

When removing the drill bit from the hole reverse the drill rotational direction.

It is recommended to keep the chuck free of dust and chips. First

remove the drill bit. Then use a wooden hammer to tap lightly on

the sides of the chuck.

CARE AND MAINTENANCE

Store the tool in a dry and well ventilated place. Minimal storage temperature is +5

0

C.

Proper care is necessary for a long trouble-free life of the tool.
Leave the tool at room temperature for 2-3 hours before use after transportation

in cold weather.

If condensation forms on the tool do not operate until the tool is completely dry.

Disconnect the tool from the power supply before cleaning or carrying

out any maintenance operations!

Always clean the tool after use. Check if the ventilation slots are clean.

Warning!

Do not try to disassemble the tool. You will void the terms and conditions

of the Warranty and Service.

Commutator service

In the course of time the commutator becomes oxidized. This will result in loss of tool per-

formance (the brushes are sparking at the commutator) and can cause damage to the motor

rotor. For commutator service please contact an authorized service centre or the factory.

Carbon brush service

The carbon brushes should be serviced after every 50 hours of operation. For brush

service please contact an authorized service centre.

Lubrication

The lubricating grease should be renewed after every 50 hours of operation. Please

contact an authorized service centre.

THE PROCEDURE OF SUBMISSION OF CONSUMER CLAIMS

The consumer has the right to file claims against the manufacturer for the non-con-

formity of products with the terms of the agreement within the term from the moment

of purchase of the product specified in European Parliament and Council Directive

99/44/EC dated May 25, 1999.

For service please contact the manufacturer or an authorized service centre directly.
