ENGLISH

en

11

turning the sleeve (2) - intermediate

settings are also possible.

= Set

drilling

 by turning the sleeve (2) (max.

torque, without torque limitation)

To avoid overloading the motor, do not

jam the spindle.

Machines with the designation SB...:

= Set

screw driving

 by turning the sleeve

(3)

AND

set the

torque

 (with torque limitation) by

turning the sleeve (4) - intermediate

settings are also possible.

= Set

drilling

 by turning the sleeve (3) (max.

torque, without torque limitation)

To avoid overloading the motor, do not

jam the spindle.

= Set

impact drilling

 by turning the sleeve

(3) (max. torque, without torque limitation)

To avoid overloading the motor, do not

jam the spindle.

6.6 Change accessory

Opening the drill chuck:

Turn the drill chuck sleeve (1) clockwise.

Clamping the tool:

Open the drill chuck and insert the tool as far as

possible. Turn the drill chuck sleeve (1) in clockwise

direction until the tool is clamped securely. With a

soft tool shank, retightening may be required after a

short drilling period.

6.7 Switching power tool on/off, setting

speed

Press the trigger switch (8) to switch on the

machine. Press in the trigger to increase the

rotational speed.

6.8 Drill chuck with "Quick" change system

(for BS 18 Quick, BS 14.4 Quick)

Removal:

See page 2, fig. A. Push the interlocking

ring forward (a) and pull off the drill chuck (b).

Mounting:

Push the interlock ring forward and

move the chuck as far as the limit stop on the drill

spindle.

6.9 Drill chuck

(for BS 14.4, BS 18, SB 18)

See page 2, fig. B.
Undo the locking screw. Caution left-handed

thread!
Clamp an Allen key in the chuck and strike lightly

with a rubber hammer to loosen, then unscrew.
Employ the same procedure when attaching the

chuck, except in reverse order.

Only use original Metabo battery packs and Metabo

accessories.
See page 4.

Only use accessories which fulfil the requirements

and specifications listed in these operating

instructions.

A Quick clamping chuck.

B Battery packs with different capacities. Only

use battery packs with voltage suitable for your

power tool.

C Angle screwdriver attachment.

D Battery  charger

E Bit holder with Quick replacement system

F Bit  box

For a complete range of accessories, see

www.metabo.com or the catalogue.

Repairs to electrical tools must ONLY be

carried out by qualified electricians!

Contact your local Metabo representative if you

have Metabo power tools requiring repairs. See

www.metabo.com for addresses.
You can download a list of spare parts from

www.metabo.com.

Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.
Battery packs may not be disposed of with regular

waste. Return faulty or used battery packs to your

Metabo dealer!
Do not allow battery packs to come into contact with

water!

Protect the environment, and do not dispose

of power tools and battery packs with house-

hold waste. Observe national regulations on

separated collection and recycling of disused

machines, packaging and accessories.
Before disposal, discharge the battery pack in the

power tool. Prevent the contacts from short-circu-

iting (e. g. by protecting them with adhesive tape).

Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
U

= Voltage of battery pack

n

= No-load speed

Tightening torque for screwing:

M

A

= soft screwing application (wood)

M

B

= hard screwing application (metal)

M

C

= adjustable torque (with torque control)

Max. drill diameter:

D

1 max

= in steel

D

2 max

= in softwood

D

3 max

= in masonry

s

= max.  impact  rate

m

= weight (with battery pack)

7. Accessories

8. Repairs

9. Environmental Protection

10. Technical Specifications
