ENGLISH

en

11

6.3 Setting the direction of rotation,

engaging the transporting safety device

(switch-on lock)

Do not activate rotation selector switch (6)

unless the motor has completely stopped!

Actuate the rotation selector switch (direction of

rotation setting, transporting safety device) (6).
See page 2:

R

= Clockwise setting

L

= Anti-clockwise setting

0

= middle position: transportation safety device

(Switch-on lock) set

6.4 Selecting gear stage

1. gear (low speed,

particularly high torque, preferable for

screwing)

2. gear (high speed, preferable for drilling)

6.5 Set torque limitation, screw driving,

drilling, impact drill

Machines with the designation BS...:

1...20 = Set

torque

 (with torque limitation) by

turning the sleeve (2) - intermediate

settings are also possible.

= Set

drilling

 by turning the sleeve (2) (max.

torque, without torque limitation)

To avoid overloading the motor, do not

jam the spindle.

Machines with the designation SB...:

= Set

screwdriving

 by turning the sleeve

(3)

AND

set the

torque

 (with torque limitation) by

turning the sleeve (4) - intermediate

settings are also possible.

= Set

drilling

 by turning the sleeve (3) (max.

torque, without torque limitation)

To avoid overloading the motor, do not

jam the spindle.

= Set

impact drilling

 by turning the sleeve

(3) (max. torque, without torque limitation)

To avoid overloading the motor, do not

jam the spindle.

6.6 Change accessory

Opening the drill chuck:

Turn the drill chuck sleeve (1) in clockwise direction.

Clamping the tool:

Open the drill chuck and insert the tool as far as

possible. Turn the drill chuck sleeve (1) in anti-

clockwise direction until the tool is clamped

securely. With a soft tool shank, retightening may

be required after a short drilling period.

6.7 On/Off switch, modifying the speed

Switching on, speed:

 press the trigger switch (7).

Press in the trigger switch to increase the rotational

speed.

Switching off:

 release the trigger switch (7).

6.8 Drill chuck with "Quick" change system

(for Powermaxx BS 12 Q)

Removal:

See page 2, fig. A. Push the interlocking

ring forward (a) and pull off the drill chuck (b).

Mounting:

Push the interlock ring forward and

move the chuck as far as the limit stop on the drill

spindle.

6.9 Protective cap - drill chuck

(for Powermaxx BS 12)

See page 2, fig. B.
When working without drill chuck, screw on the

protective cap (16).

Fit the drill chuck:

 unscrew protective cap (16).

Screw on the quick clamping drill chuck onto the

spindle thread and tighten with an open-jawed

spanner (

and remove in the same manner if

needed

).

6.10 Drill chuck (for Powermaxx SB 12)

See page 2, fig. C.
Remove locking screw. Caution left-handed thread!
Clamp an Allen key in the chuck and strike lightly

with a rubber hammer to loosen, then unscrew.
Employ the same procedure when attaching the

chuck, except in reverse order.

Use only original Metabo or CAS (Cordless Alliance

System) battery packs and accessories.
See page 3, fig. D.
Use only accessories that fulfil the requirements

and specifications listed in these operating

instructions.

A Quick-clamping chuck.

B Battery packs with different capacities. Buy

battery packs only with voltage suitable for your

power tool.

C Angle screwdriver attachment.

D Battery  charger

E Bit holder with Quick replacement system

F Bit  box

For a complete range of accessories, see

www.metabo.com or the catalogue.

Repairs to electrical tools must ONLY be

carried out by qualified electricians!

Contact your local Metabo representative if you

have Metabo power tools requiring repairs. See

www.metabo.com for addresses.
You can download a list of spare parts from

www.metabo.com.

Observe the national regulations on

environmentally compatible disposal and on the

1

2

1

2

7. Accessories

8. Repairs

9. Environmental Protection
