ENGLISH

en

13

7.10 Attaching the belt hook (depending on

machine features)/bit depot (depending

on machine features)

Fig. J

Attach the belt hook to the left (6), as shown.
Attach the bit depot to the right (5), as shown.

8.1

The machine's multifunctional monitoring

system

If the machine switches off automatically, the
machine electronics have activated automatic

protection mode. A warning signal sounds (contin-
uous beeping). The beeping stops after a maximum
of 30 seconds or when the trigger  (12) is released.

In spite of this protective function, overloading
is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1.

Battery pack almost empty

Fig. A, B

(The

electronics protect the battery pack against
damage through total discharge).
If one LED is flashing (9), the battery pack is
almost flat. If necessary, press the  (8) button
and check the LEDs  (9) to see the charge level.
If the battery pack is almost flat, it must be
recharged.

2. Long continuous overloading of the machine will

activate the

temperature cut-out

.

Leave the machine or battery pack to cool.
Note: If the battery pack feels very warm, the
pack will cool more quickly in an "AIR COOLED"
charger.
Note: The machine will cool more quickly if you
operate it at idling speed.

3. Metabo

safety shutdown

: The machine was

SWITCHED OFF automatically. If the slew rate
of the current is too high (for example, if the
machine suddenly seizes or kickback occurs),
the machine switches off. Switch off the machine
at the trigger (12). Switch it on again and
continue to work as normal. Try to prevent the
machine from seizing.

Switch off the machine at the trigger (12). Then
continue working as normal. Try to prevent the
machine from seizing.

Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating instruc-
tions.
Fitting the angle drilling attachment

Fig. K

.

For a complete range of accessories, see
www.metabo.com or the main catalogue.

Repairs to electrical tools must be carried out
by qualified electricians ONLY!

If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
You can download spare parts lists from
www.metabo.com.

Do not allow battery packs to come into contact with
water!

To protect the environment, do not dispose of
power tools or battery packs in household
waste. Observe national regulations on

separated collection and recycling of disused
machines, packaging and accessories.
Before disposal, discharge the battery pack in the
power tool. Prevent the contacts from short-
circuiting (e. g. by protecting them with adhesive
tape).

Fig. L.

We reserve the right to make technical

improvements.
U

=

Voltage of battery pack

n

0

=

No-load speed

Tightening torque for screwing:
M

1

=

Soft screwing application (wood)

M

3

=

Hard screwing application (metal)

M

4

=

Adjustable torque

Max. drill diameter:
D

1 max

=

in steel

D

2 max

=

in softwood

D

3 max

=

in concrete

s

=

Max.  impact  rate

m

=

Weight (with smallest battery pack)

G

=

Spindle  thread

D

 max

=

Chuck clamping range

Measured values determined in conformity with
EN 60745.

Direct current

The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).

Emission values

Using these values, you can estimate the

emissions from this power tool and compare these
with the values emitted by other power tools. The
actual values may be higher or lower, depending on
the particular application and the condition of the
tool or power tool. In estimating the values, you
should also include work breaks and periods of low
use. Based on the estimated emission values,
specify protective measures for the user - for
example, any organisational steps that must be put
in place.
Vibration total value (vector sum of three directions)
determined in accordance with EN 60745:
a

h, ID

=

Vibration emission value
(impact drilling into concrete)

a

h, D

=

Vibration emission value
(drilling into metal)

8. Troubleshooting

9. Accessories

10. Repairs

11. Environmental Protection

12. Technical specifications
