ENGLISH

en

11

The screwdriver bit is retained if a bit clamping bush

(as an accessory: order no. 6.31281) is fitted.

Futuro Plus keyless chuck

See page 4, illustration A.
Unscrew the safety screw - if available. Caution:

left-handed thread!
Hold the drill spindle securely using an open-end

wrench. Clamp an Allen key in the chuck and strike

lightly with a rubber hammer to loosen, then

unscrew.

Geared chuck

See page 4, illustration B.
Unscrew the safety screw - if available. Caution:

left-handed thread!
Hold the drill spindle securely using an open-end

wrench. Insert the key in the chuck and strike lightly

with a rubber hammer to loosen, then unscrew.

8. Maintenance

Keyless chuck cleaning:



After prolonged use hold the chuck vertically, with

the opening facing down, and fully open and close it

several times. The dust collected falls from the

opening. Regular use of cleaning spray on the jaws

and jaw openings is recommended.

f

9. Accessories

Use only genuine Metabo accessories.
Use only accessories which fulfil the requirements

and specifications listed in these operating instruc-

tions.
Fit accessories securely. Secure the machine if it is

operated in a bracket. Loss of control can cause

personal injury.
For a complete range of accessories, see

www.metabo.com or the main catalogue.

10. Repairs

Repairs to electrical tools must be carried out by

qualified electricians ONLY!
Contact your local Metabo representative if you

have Metabo power tools requiring repairs. For

addresses see www.metabo.com.
You can download a list of spare parts from

www.metabo.com.

11. Environmental Protection

Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.

Only for EU countries: Never dispose of

power tools in your household waste! In

accordance with European Guideline 2002/

96/EC on used electronic and electric

equipment and its implementation in national legal

systems, used power tools must be collected

separately and handed in for environmentally

compatible recycling.

12. Technical Specifications

Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
P

1

= Nominal power input

P

2

= Power output

n

0

= No load speed

n

1

= Speed at rated load

ø max = Max. solid drill diameter

s max = Max. impact rate

G

= Drill spindle thread

H

= Drill spindle with hexagon socket

m

= Weight without mains cable

D

= Collar diameter

Measured values determined in conformity with

EN 60745.

Machine in protection class II

~

Alternating current

The technical specifications quoted are subject to

tolerances (in compliance with the relevant valid

standards).

Emission values

Using these values, you can estimate the emis-

sions from this power tool and compare these with

the values emitted by other power tools. The actual

values may be higher or lower, depending on the

particular application and the condition of the tool or

power tool. In estimating the values, you should also

include work breaks and periods of low use. Based

on the estimated emission values, specify protective

measures for the user - for example, any organisa-

tional steps that must be put in place.
Vibration total value (vector sum of three directions)

determined in accordance with EN 60745:

a

h, ID

= Vibration emission value (impact drilling

into concrete)

a

h, D

= Vibration emission value



(drilling into metal)

K

h,ID

,K

h,D

=Uncertainty (vibration)

Typical A-effective perceived sound levels:

L

pA

= Sound  pressure  level

L

WA

= Acoustic  power  level

K

pA

, K

WA

= Uncertainty

During operation the noise level can exceed

80 dB(A).

Wear ear protectors!


