ENGLISH

en

10

SBE 561, SBE 550, SBE 521, BE 561:



Make sure the chuck clamps securely:

After drilling for the first time (clockwise), firmly

tighten the safety screw inside the chuck using



a screwdriver. Caution: left-handed thread!



(see Section 7.8)

6.1 Attaching the Additional Handle



(SBE 561, SBE 550, SBE 521, SB 561)

For safety reasons, always use the



additional handle supplied.

Open the clamping ring by turning the additional

handle (5) anticlockwise. Push the additional

handle onto the collar of the machine. Insert the

depth stop (4). Securely tighten the additional

handle at the angle required for the application.

7. Use

7.1 Adjusting the Depth Stop



(SBE 561, SBE 550, SBE 521, SB 561)

Loosen the additional handle (5). Set depth stop (4)

to the desired drilling depth and retighten additional

handle.

7.2 Switching On and Off

To start the machine, press the trigger switch (9).
SBE 561, SBE 550, SBE 521, BE 561: Press in the

trigger switch to change the speed.
For continuous operation the trigger switch can be

locked using the lock button (8). To stop the

machine, press the trigger switch again.

In continuous operation, the machine

continues running if it is forced out of your

hands. Therefore, always hold the machine

with both hands using the handles provided,

stand in a safe position and concentrate.

7.3 Speed Preselection



(SBE 561, SBE 550, SBE 521, BE 561)

Select the (10) maximum speed using the

preselection wheel. See page 4 for recommended

drilling speeds.

7.4

Switching Between Normal Drilling/

Impact Drilling



(SBE 561, SBE 550, SBE 521, SB 561)

Select the desired operating mode by pushing the

sliding switch (7).

Drilling



Impact drilling




Work with high speed settings when impact drilling.

Impact drilling and normal drilling only in

a clockwise direction.

7.5 Selecting the Direction of Rotation



(SBE 561, SBE 550, SBE 521, BE 561)

Do not activate the direction switch (6)

unless the motor has completely stopped.

Select direction of rotation:

R = Clockwise

L = Anticlockwise

Screw the chuck firmly to the spindle and

tighten the safety screw inside the chuck

using a screwdriver. (Caution: left-handed

thread!)



Otherwise it may come loose during

anticlockwise operation (e.g. when

screwdriving).

7.6 Tool Change With



Futuro Plus Keyless Chuck (3)

Machines with the designation SB...:

See illustrations on page 2.
Insert the tool. Hold the retaining ring (a) firmly and

turn the collet (b) towards "GRIP, ZU" with the other

hand until the mechanical resistance which can be

felt is overcome.



Caution! The tool is not yet clamped!

 Keep

turning the sleeve (

it must "click" when turning

)

until it cannot be turned any further -

only now

 is the

tool

securely

 clamped.

With a soft tool shank, retightening may be required

after a short drilling period.
Open the chuck:



Hold the retaining ring (a) firmly and turn the collet

(b) towards "AUF, RELEASE" with the other hand.

Note:

The grating sound which may be heard after

opening the drill chuck is functional and is stopped

by turning the sleeve in the opposite direction.

If the chuck is very securely tightened:

Unplug.

Hold the drill chuck using an open-end spanner at

the flats on its head, and turn the sleeve (b)

vigourously in the direction of "AUF, RELEASE".

Machines with the designation B...:

See illustrations on page 2.
Insert the tool. Hold the retaining ring (a) firmly and

turn the collet (b) towards "GRIP, ZU" with the other

hand until it will not turn any further.
With a soft tool shank, retightening may be required

after a short drilling period.
Open the chuck:



Hold the retaining ring (a) firmly and turn the collet

(b) towards "AUF, RELEASE" with the other hand.

If the chuck is very securely tightened:

Unplug.

Hold the drill chuck using an open-end spanner at

the flats on its head, and turn the sleeve (b)

vigourously in the direction of "AUF, RELEASE".

7.7 Tool Change With



Geared Chuck (2)

See illustrations on page 2.

Clamping tools:



Insert the tool and clamp evenly in all 3 holes using

the chuck key (1).

Removing tools:



Open the geared chuck (2) using the chuck key (1)

and remove the tool.

7.8 Removing the Chuck

SBE 561, SBE 550, SBE 521, BE 561: The chuck

can be removed to insert a screwdriver bit. Insert

the bit directly in the hexagon socket on the spindle.


