9 ENGLISH

Electronic function

The tool is equipped with the electronic functions for

easy operation.

•

Soft start

The soft-start function minimizes start-up shock,

and makes the tool start smoothly.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Installing the front cover and side

grip

CAUTION:

Tighten the side grip firmly.

Otherwise, the front cover may fall and cause an

injury.

►

Fig.7:

1.

 Front cover

2.

 Side grip

Attach the front cover to the tool and screw the side grip

on the tool securely.

The side grip can be installed on either side of the tool.

Installing the shaft

Optional accessory

For DUT130
1.

Tighten the shaft into the shaft holder.

►

Fig.8:

1.

 Shaft

2.

 Shaft holder

2.

Tighten the shaft with wrench 19 while holding the

shaft holder with another wrench 19.

►

Fig.9:

1.

 Shaft

2.

 Shaft holder

For DUT131
1.

Insert the shaft into the chuck as far as it will go.

►

Fig.10:

1.

 Shaft

2.

 Chuck

2.

  Tighten the chuck by hand, and then place the

chuck key in each of three holes and tighten it clock

-

wise. Be sure to tighten the chuck key at all three holes

evenly.

►

Fig.11:

1.

 Chuck key

2.

 Chuck

To remove the shaft, turn the chuck key counterclock

-

wise at one of the holes, and then loosen the chuck by

hand.

Installing the mixing blade

Optional accessory

Attach the mixing blade on the top of the shaft, and then

secure it with the hex bolt.

►

Fig.12:

1.

 Mixing blade

2.

 Shaft

3.

 Hex bolt

NOTICE:

Be sure to attach the mixing blade with

"UP" mark facing the tool.

►

Fig.13:

1.

 Mark

Hook

Optional accessory

CAUTION:

Always remove the battery when

hanging the tool with the hook.

CAUTION:

Never hook the tool at high loca-

tion or on potentially unstable surface.

►

Fig.14:

1.

 Groove

2.

 Hook

3.

 Screw

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool.

To install the hook, insert it into a groove in the tool

housing on either side and then secure it with a screw.

To remove, loosen the screw and then take it out.

Installing or removing the shaft

holder

Optional accessory

For DUT131
1.

Insert the hex wrench into the chuck, and then

loosen the chuck with the hex wrench while holding the

spindle with the wrench.

►

Fig.15:

1.

 Hex wrench

2.

 Chuck

3.

 Wrench

2.

Tighten the shaft holder with a wrench 19 while

holding the spindle with another wrench 19.

►

Fig.16:

1.

 Shaft holder

2.

 Wrench

To remove the shaft holder, perform the installation

procedure in reverse.

OPERATION

CAUTION:

Do not mix flammable materials or

operate the tool around flammable materials such

as paint with thinner used as solvent.

 Failure to do

so may cause an injury.

CAUTION:

Do not mix high viscosity material,

such as mortar or adhesive, in the high speed

mode.

 You may lose the control of the tool and cause

an injury.

NOTICE:

When you mix the material while the

mixing blade floating out of the material, be care

-

ful not to splash the material.

1.

Select high speed or low speed according to the

material to be mixed.

2.

Hold the rear handle of the tool with one hand

and the grip with the other hand firmly, place the mixing

blade under material fully and turn on the tool after

making sure work site safety.

3.

Move the mixing blade up and down during the

mixing operation so that whole part of material can be

mixed.

4.

  When finishing mixing, turn off the tool, make sure

that the mixing blade has come to a complete stop, and

then pull it out of the mixing container.
