9 ENGLISH

Installing hook

CAUTION:



When installing the hook, always

secure it with the screw firmly.

 If not, the hook may

come off from the tool and result in the personal injury.

CAUTION:



Use the hanging/mounting parts for

their intended purposes only.

 Using for unintended

purpose may cause accident or personal injury.

►

Fig.12:



1.

 Groove

2.

 Hook

3.

 Screw

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool. To install

the hook, insert it into a groove in the tool housing on

either side and then secure it with a screw. To remove,

loosen the screw and then take it out.

NOTICE:



When hanging the tool on your belt

using the hook, remove the bit and the side grip.

Installing driver bit holder

Optional accessory

►

Fig.13:



1.

 Driver bit holder

2.

 Driver bit

Fit the driver bit holder into the protrusion at the tool foot

on either right or left side and secure it with a screw.

When not using the driver bit, keep it in the driver bit

holders. Driver bits 45 mm-long (1-3/4") can be kept

there.

OPERATION

Hold the tool firmly with one hand on the grip and the

other hand on the handle to control the twisting action.

►

Fig.14

NOTICE:

 When the speed comes down extremely,

reduce the load or stop the tool to avoid the tool

damage.

NOTICE:

 Do not cover vents, or it may cause over-

heating and damage to the tool.

►

Fig.15:



1.

 Vent

Screwdriving operation

CAUTION:



Adjust the adjusting ring to the

proper torque level for your work.

CAUTION:



Make sure that the driver bit is

inserted straight in the screw head, or the screw

and/or driver bit may be damaged.

First, turn the adjusting ring so that the arrow on the tool

body points to the proper fastening torque level (1 - 21).

Place the point of the driver bit in the screw head and

apply pressure to the tool. Start the tool slowly and then

increase the speed gradually. Release the switch trigger

as soon as the clutch cuts in.

NOTE:

 When driving wood screw, pre-drill a pilot hole

2/3 the diameter of the screw. It makes driving easier

and prevents splitting of the workpiece.

Hammer drilling operation

CAUTION:



There is a tremendous and sudden

twisting force exerted on the tool/drill bit at the

time of hole breakthrough, when the hole becomes

clogged with chips and particles, or when striking

reinforcing rods embedded in the concrete.

First, turn the adjusting ring so that the arrow on the tool

body points to the

 marking.

Be sure to use a tungsten-carbide tipped drill bit.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.

Do not apply more pressure when the hole becomes clogged with

chips or particles. Instead, run the tool at an idle, then remove the

drill bit partially from the hole. By repeating this several times, the

hole will be cleaned out and normal drilling may be resumed.

Blow-out bulb

Optional accessory

►

Fig.16:



1.

 Blow-out bulb

After drilling the hole, use the blow-out bulb to clean the

dust out of the hole.

Drilling operation

CAUTION:



Pressing excessively on the tool will

not speed up the drilling.

 In fact, this excessive pressure

will only serve to damage the tip of your drill bit, decrease

the tool performance and shorten the service life of the tool.

CAUTION:



Hold the tool firmly and exert care

when the drill bit begins to break through the

workpiece.

 There is a tremendous force exerted on

the tool/drill bit at the time of hole break through.

CAUTION:



A stuck drill bit can be removed

simply by setting the reversing switch to reverse

rotation in order to back out. However, the tool

may back out abruptly if you do not hold it firmly.

CAUTION:



Always secure workpieces in a

vise or similar hold-down device.

CAUTION:



If the tool is operated continuously until

the battery cartridge has discharged, allow the tool to rest

for 15 minutes before proceeding with a fresh battery.

First, turn the adjusting ring so that the arrow points to

the

 marking. Then proceed as follows.

Drilling in wood

When drilling in wood, the best results are obtained with

wood drills equipped with a guide screw. The guide screw

makes drilling easier by pulling the drill bit into the workpiece.

Drilling in metal

To prevent the drill bit from slipping when starting a

hole, make an indentation with a center-punch and

hammer at the point to be drilled. Place the point of the

drill bit in the indentation and start drilling.

Use a cutting lubricant when drilling metals. The excep-

tions are iron and brass which should be drilled dry.
