8 ENGLISH

Speed change

CAUTION:



Always set the speed change lever

fully to the correct position.

 If you operate the tool with

the speed change lever positioned halfway between the

"1" side and "2" side, the tool may be damaged.

CAUTION:



Do not use the speed change lever

while the tool is running.

 The tool may be damaged.

►

Fig.6:



1.

 Speed change lever

Displayed

Number

Speed

Torque

Applicable

operation

1

Low

High

Heavy load-

ing operation

2

High

Low

Light loading

operation

To change the speed, switch off the tool first. Push the

speed change lever to display "2" for high speed or "1"

for low speed. Be sure that the speed change lever is

set to the correct position before operation.

If the tool speed is coming down extremely during the operation with

display "2", push the lever to display "1" and restart the operation.

Adjusting ring

You can select the action mode and adjust the fastening

torque with the adjusting ring.

Selecting the action mode

►

Fig.7:



1.

 Adjusting ring

2.

 Mark

3.

 Arrow

This tool has three action modes.

Drilling mode (rotation only)

Hammer drilling mode (rota-

tion with hammering)

1 - 21

Screwdriving mode (rotation

with clutch)

Select the mode suitable for your work. Turn the adjust

-

ing ring and align the mark that you select with the

arrow on the tool body.

NOTICE:

 Always set the ring correctly to your desired

mode mark. If you operate the tool with the ring positioned

halfway between the mode marks, the tool may be damaged.

NOTICE:

 Do not change the action mode while tool is rotating.

Adjusting the fastening torque

►

Fig.8:



1.

 Adjusting ring

2.

 Mark (1 - 21 graduation)

3.

 Arrow

The fastening torque can be adjusted in 21 levels by turning the adjusting ring. Align the graduations with the arrow

on the tool body. You can get the minimum fastening torque at 1 and maximum torque at 21.

Before actual operation, drive a trial screw into your material or a piece of duplicate material to determine which

torque level is required for a particular application.

Graduation

1

2

3

4

5

6

7

8

9

10 11 12 13 14 15 16 17 18 19 20 21

Machine screw

M4

M5

M6

Wood

screw

Soft

wood

(e.g.

pine)

ø

3.5 x 22

ø4.1 x 38

ø5.1 x 50

Hard

wood

(e.g.

lauan)

ø

3.5 x 22

ø4.1 x 38

ø5.1 x 50

NOTE:

 The adjusting ring does not lock when the arrow is positioned only halfway between the graduations.

ASSEMBLY

CAUTION:



Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing driver bit/

drill bit

Optional accessory

►

Fig.9:



1.

 Sleeve

2.

 Close

3.

 Open

Turn the sleeve counterclockwise to open the chuck jaws.

Place the driver bit/drill bit in the chuck as far as it will go.

Turn the sleeve clockwise to tighten the chuck. To remove

the driver bit/drill bit, turn the sleeve counterclockwise.

Installing side grip (auxiliary handle)

►

Fig.10:



1.

 Side grip

2.

 Protrusion

3.

 Groove

4.

 Arm

Always use the side grip to ensure operating safety.

Install the side grip so that the protrusions on the arm fit

in the grooves on the tool barrel. Turn the grip clockwise

to secure it. The grip can be fixed at desired angle.

Adjustable depth rod

►

Fig.11:



1.

 Depth rod

2.

 Clamp screw

The adjustable depth rod is used to drill holes of uniform

depth. Loosen the clamp screw, set the depth rod to

desired position, then tighten the clamp screw.
