9 ENGLISH

Reversing switch action

►

Fig.5:

1.

 Reversing switch lever

CAUTION:

Always check the direction of

rotation before operation.

CAUTION:

Use the reversing switch only after

the tool comes to a complete stop.

 Changing the

direction of rotation before the tool stops may dam

-

age the tool.

CAUTION:

When not operating the tool,

always set the reversing switch lever to the neu

-

tral position.

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the

A side for clockwise rotation or from the B side for coun

-

terclockwise rotation.

When the reversing switch lever is in the neutral posi-

tion, the switch trigger cannot be pulled.

Speed change

►

Fig.6:

1.

 Speed change lever

CAUTION:

Always set the speed change lever

fully to the correct position.

 If you operate the

tool with the speed change lever positioned halfway

between the "1" side and "2" side, the tool may be

damaged.

CAUTION:

Do not use the speed change lever

while the tool is running.

 The tool may be damaged.

Position of

speed

change lever

Speed

Torque

Applicable

operation

1

Low

High

Heavy load-

ing operation

2

High

Low

Light loading

operation

To change the speed, switch off the tool first. Select

the "2" side for high speed or "1" for low speed but high

torque. Be sure that the speed change lever is set to the

correct position before operation.

If the tool speed is coming down extremely during the

operation with "2", slide the lever to the "1" and restart

the operation.

Adjusting the fastening torque

►

Fig.7:

1.

 Adjusting ring

2.

 Graduation

3.

 Arrow

The fastening torque can be adjusted in 21 levels by turning the adjusting ring. Align the graduations with the arrow
on the tool body. You can get the minimum fastening torque at 1 and maximum torque at

marking.

The clutch will slip at various torque levels when set at the number 1 to 20. The clutch does not work at

the

marking.

Before actual operation, drive a trial screw into your material or a piece of duplicate material to determine which

torque level is required for a particular application.

The following shows the rough guide of the relationship between the screw size and graduation.

Graduation

1

2

3

4

5

6

7

8

9

10 11 12 13 14 15 16 17 18 19 20

Machine screw

M4

M5

M6

Wood

screw

Soft wood

(e.g. pine)

–

ɸ

3.5 x 22

ɸ

4.1 x 38

–

Hard wood

(e.g. lauan)

–

ɸ

3.5 x 22

ɸ

4.1 x 38

–

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing driver bit/

drill bit

For Model DF332D (optional accessory)

►

Fig.8:

1.

 Sleeve

2.

 Close

3.

 Open

Turn the sleeve counterclockwise to open the chuck jaws.

Place the driver bit/drill bit in the chuck as far as it will go.

Turn the sleeve clockwise to tighten the chuck. To remove

the driver bit/drill bit, turn the sleeve counterclockwise.

Installing or removing driver bit/

socket bit

For Model DF032D (optional accessory)

►

Fig.9

Use only driver bit/socket bit that has inserting portion

shown in the figure. Do not use any other driver bit/

socket bit.

For tool with shallow driver bit hole

A=12mm

B=9mm

Use only these type of driver

bit. Follow the procedure

1. (Note) Bit-piece is not

necessary.
