English

10

period is not activated, the electric discharge might
be low when using them the first and second time.
This is a temporary phenomenon, and normal time
required for recharging will be restored by recharging
the batteries 2 – 3 times.

How to make the batteries perform longer.

(1) Recharge the batteries before they become completely

exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery.
If you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.

(2) Avoid recharging at high temperatures.

A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate,
and the battery life will be shortened. Leave the battery
and recharge it after it has cooled for a while.

CAUTION

䡬

When the battery charger has been continuosly used,
the battery charger will be heated, thus constituting
the cause of the failures. Once the charging has been
completed, give 15 minutes rest until the next
charging.

䡬

If the battery is recharged when it is warm due to
battery use or exposure to sunlight, the pilot lamp
map light in green.
The battery will not be recharged. In such a case, let
the battery cool before charging.

䡬

When the pilot lamp flickers in red (at 0.2-second
intervals), check for and take out any foreign objects
in the charger’s battery installation hole. If there are
no foreign objects, it is probable that the battery or
charger is malfunctioning. Take it to your authorized
Service Center.

PRIOR TO OPERATION

1. Setting up and checking the work environment

Check if the work environment is suitable by following
the precautions.

HOW TO USE

1. Confirm the cap position (see Fig. 4)

The three modes of screwdriver, drill and impact drill
can be switched by the position of the cap in this unit.

(1) When using this unit as a screwdriver, line up the one

of the numbers “1, 4, 7 ... 22” on the cap, or the black
dots, with the triangle mark on the outer body.

(2) When using this unit as a drill, align the cap drill mark

“

” with the triangle mark on the outer body.

(3) When using this unit as an impact drill, align the cap

hammer mark “

” with the triangle mark on the

outer body.

CAUTION

䡬

The cap cannot be set between the numerals “1, 4, 7
... 22” or the black dots.

䡬

Do not use with the cap numeral between “22” and
the black line at the middle of the drill mark. Doing so
may cause damage (See

Fig. 5

).

2. Tightening torque adjustment

(1) Tightening torque

Tightening torque should correspond in its intensity
to the screw diameter. When too strong torque is
used, the screw head may be broken or be injured.
Be sure to adjust the cap position according to the
screw diameter.

(2) Tightening torque indication

The tightening torque differs depending on the type
of screw and the material being tightened.
The unit indicates the tightening torque with the
numbers “1, 4, 7 ... 22” on the cap, and the black
dots. The tightening toque at position “1” is the
weakest and the torque is strongest at the highest
number (See

Fig. 4

).

(3) Adjusting the tightening torque

Rotate the cap and line up the numbers “1, 4, 7 ... 22”
on the cap, or the black dots, with the triangle mark
on the outer body. Adjust the cap in the weak or the
strong torque direction according to the torque you
need.

CAUTION

䡬

The motor rotation may be locked to cease while the
unit is used as drill. While operating the impact driver
drill, take care not to lock the motor.

䡬

Too long hammering may cause the screw broken
due to excessive tightening.

3. Rotation to Impact changeover (See Fig. 4)

The “Rotation (Rotation only)” and “Impact (Impact
+ Rotation)” can be switched by aligning the drill
mark “

” or the hammer mark “

” with the triangle

mark on the outer body.

䡬

To make holes in the metal, wood or plastic, switch
to “Rotation (Rotation only)”.

䡬

To make holes in bricks or concrete blocks, switch to
“Impact (Impact + Rotation)”.

CAUTION

If an operation which is normally performed at the
“Rotation” setting is performed at “Impact “ setting,
the effect of making holes does not only increase but
it may also damage the bit or other parts.

4. Change rotation speed

By making a combination of the switch-over of “HIGH”
or “LOW” with the shift knob and the switch-over of
Power mode (P) or Save mode (S) with the lever on
the side of the handle, the rotational speed can be set
to four (4) steps. (See “SPECIFICATIONS”.)

䡬

How to switch over “HIGH” or “LOW”
Operate the shift knob to change the rotational speed.
Move the shift knob in the direction of the arrow (see

Figs. 6

 and

7

).

When the shift knob is set to “LOW”, the drill rotates
at a low speed. When set to “HIGH”, the drill rotates
at a high speed.

䡬

How to switch over the Power mode (P) or Save
mode (S)
To set to the Power mode (P), slide the lever on the
side of handle to the lower side, and to set to the Save
mode (S), slide the lever to the upper side. (

Fig. 8

)

CAUTION

䡬

When changing the rotational speed with the shift
knob, confirm that the switch is off.
Changing the speed while the motor is rotating will
damage the gears.
