15

•

Do not use water or any other liquid for cleaning.

•

Clean the device with a dry cloth or blow through with

compressed air at low pressure

•

Do not use any cleaning agents or solvents, they may damage

plastic parts.

•

Clean ventilation holes in the motor casing regularly to

prevent device overheating.

•

Always store the tool in a dry place, beyond reach of children.

•

Store the device with the battery removed.

All defects should be repaired by service workshop authorized

by the manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS

Cordless drill 58G022

Parameter

Value

Battery voltage

18 V DC

Range of idle rotational speed

gear I

0-350 rpm

gear II

0-1250 rpm

Range of quick release chuck

0,8 - 10 mm

Tool holder

6,35 mm (¼ ‘’)

Torque control range

 1–19 + drilling

Max. torque (soft drive)

28 Nm

Max. torque (hard drive)

44 Nm

Protection class

III

Weight

1,1 kg

Year of production

2020

58G022 defines type and indication of the device

Graphite Energy+ System Battery

Parameter

Value

Battery

58G001

58G004

Battery voltage

18 V DC

18 V DC

Battery type

Li-Ion

Li-Ion

Battery capacity

2000 mAh

4000 mAh

Ambient temperature range

4

0

C – 40

0

C

4

0

C – 40

0

C

Charging time for charger 58G002

1 h

2 h

Weight

0,400 kg

0,650 kg

Year of production

2020

2020

Graphite Energy+ System Charger

Parameter

Value

Charger type

58G002

Supply voltage

230 V AC

Power supply frequency

50 Hz

Charging voltage

22 V DC

Max. charging current

2300 mA

Ambient temperature range

4

0

C – 40

0

C

Charging time of the battery 58G001

1 h

Charging time of the battery 58G004

2 h

Protection class

II

Weight

0,300 kg

Year of production

2020

NOISE LEVEL AND VIBRATION PARAMETERS

Sound pressure

Lp

A

= 84 dB(A) K= 3 dB(A)

Sound power

Lw

A

= 95 dB(A) K= 3 dB(A)

Vibration acceleration

a

h

= 1,552 m/s

2

 K= 1,5 m/s

2

Noise and vibration information

Noise produced by the device is defined with: level of produced

sound pressure Lp

A

 and level of sound power Lw

A

(where K is

measurement uncertainty). Vibrations produced by the device

are defined with vibration acceleration value a

h

 (where K is

measurement uncertainty).

Sound pressure Lp

A

, sound power Lw

A

 and vibration acceleration

ah specified in this manual have been measured in accordance

with EN 60745-1:2009+A11:2010. Specified vibration level a

h

 can

be used to compare tools and for initial evaluation of exposition

to vibrations.

Specified vibration level is representative for main applications

of the device. When the device is used for other purposes or

with different working tools, the vibration level may change.

Insufficient or too rare maintenance may increase vibration

level. The abovementioned factors may lead to higher exposure

to vibrations during whole working time.

To precisely define exposure to vibrations, include periods

when the device is switched off and when it is switched on

but not used for working. Once all factors have been carefully

considered, total exposition to vibrations may be significantly

lower.

To protect the user from results of exposure to vibrations, use

additional safety measures such as: device and working tool

periodic maintenance, proper hand temperature conditions,

good work organisation.

ENVIRONMENTAL PROTECTION

Electrical equipment must not be disposed off

with household waste and, instead, should be

utilized at appropriate facilities. Information

on utilization can be provided by the product

vendor or the local authorities. Waste electrical

and electronic equipment contains substances

that are not neutral to the natural environment.

Equipment that is not recycled constitutes a

potential hazard to the environment and to

human health.

Li-Ion

Storage batteries/batteries must not be disposed

with domestic waste, put in a fire or into the

water. Damaged or used up storage batteries

must be properly recycled in compliance with the

current directive pertaining to disposal of storage

batteries and batteries.

* Right to introduce changes is reserved.
