BAT TERY LEVEL INDICATION

The battery is equipped with signalisation of the battery level (3

LED diodes) (

14

). To check battery level status, press the button

for battery level indication (

13

) (

fig. C

). When all diodes are lit,

the battery level is high. When 2 diodes are on, the battery is

partially discharged. When only one diode is lit, the battery is

discharged and must be recharged.

SPINDLE BRAKE

Drill is equipped with electronic brake that stops the spindle

immediately after the switch button (

9

) is released. The brake

ensures precision when screwing or drilling and prevents free

spindle rotation after switching off.

OPERATION / SET TINGS

SWITCHING ON / SWITCHING OFF
Switching on

– press the switch button (

9

).

Switching off

 – release the switch button (

9

).

 Each time the switch button (

9

) is pressed, the LED diode (

10

)

lights up to illuminate the workplace.

ROTATIONAL SPEED CONTROL

Increase or reduce pressure on the switch button (

9

) to adjust

drilling or driving speed while operating. Speed adjustment

allows for a soft start, which prevents dill slipping when drilling

holes in gypsum or glaze, and allows for operation control when

driving screws in and out.

OVERLOAD CLUTCH

Set the torque adjustment ring (

3

) in appropriate position

to permanently set overload clutch to defined torque value.

When the set torque is reached, overload clutch disconnects

automatically. It prevents from driving screws too deep or

damaging the drill.

TORQUE ADJUSTMENT

•

Different screws and materials require different torque to be

applied.

•

The bigger the number corresponding to given position, the

bigger is the torque (

fig. D

).

•

Set the torque adjustment ring (

3

) to appropriate torque value.

•

Always start operation with low torque.

•

Increase the torque gradually until obtaining desired results.

•

Use higher settings to undo screws.

•

When drilling, choose setting marked with the drill symbol.

The torque is the greatest with this setting.

•

Knowledge how to choose appropriate torque setting comes

with practice.

Setting the torque adjustment ring in the drilling position

deactivates the overload clutch.

INSTALLATION OF WORKING TOOL IN THE DRILL CHUCK

•

Set the direction selector switch (

5

) in the middle position.

•

By turning the ring of the quick release chuck (

2

) counter

clockwise (see mark on the ring) you can spread jaws enough to

insert drill or driver bit (

fig. E

).

•

To fix the working tool, turn the ring of the quick release chuck (

2

)

clockwise and tighten firmly.

Deinstallation of the working tool is similar to installation, only the

sequence of actions is reversed.

Make sure the tool position is correct when installing drill or driver

bit in the quick release chuck. Use additional magnetic adapter as

an extension when using short driver bits.

DRILL CHUCK INSTALLATION AND REMOVAL

•

Pull the locking ring (

15

) forward and slide the drill chuck (

1

) off

the spindle (

fig. F

).

•

Installation of the drill chuck (

1

) is similar to removal, only the

sequence of actions is reversed.

•

Pull the locking ring (

15

) away and slide the drill chuck (

1

) onto

the spindle until you can clearly hear the lock snaps in (it may

be necessary to rotate the drill chuck slightly so it can reach

appropriate position).

INSTALLATION AND REPLACEMENT OF WORKING TOOLS IN

THE SPINDLE HOLDER

•

Place appropriate working bit directly in the spindle holder (

16

)

(

fig. G

).

•

Ensure the bit is inserted to the end and is properly installed.

•

To remove the working tool, pull the working bit out of the spindle

holder.

Use additional driver bit adapter with short driver bits. It is

recommended to always make a pilot hole before screwing screws

with the screwdriver. When a short driver bit is installed in the

spindle, it is not necessary to remove it when installing the drill

chuck (

fig. H

).

RIGHT-LEFT DIRECTION OF ROTATION

Choose direction of spindle rotation with the direction selector

switch (

5

) (

fig. I

).

Clockwise rotation

 – set the switch (

5

) to the extreme left

position.

Counter-clockwise rotation

– set the switch (

5

) to the extreme

right position.

* In certain cases position of the switch related to rotation may be different

than specified. Please refer to graphic signs located on the switch or tool

body.

Safe position of the direction selector switch (

5

) is in the middle,

it prevents accidental starting of the power tool.

•

Drill cannot be started, when the switch is in this position.

•

Use this position of the switch to change drills or bits.

•

Before starting the tool make sure the position of the direction

selector switch (

5

) is correct.

Do not change direction of rotation when the drill spindle

is rotating.
CHANGE OF GEAR

Gear switch (

4

) (

fig. J

) allows to increase the range of rotational

speed.

Gear I:

small speed range, big torque

Gear II:

greater speed range, small torque.

Set the gear switch in position appropriate for the works to

perform. When the switch is blocked and cannot be moved, turn

the spindle slightly.

Never change the gear switch position when the drill is

operating. It may damage the power tool.

Long lasting drilling at low rotational speed of the spindle

may cause motor overheating. Make periodic breaks in

operation or allow the tool to operate at top speed without

load for approximately 3 minutes.
HOLDER

The drill provides convenient holder (

6

) that allows to e.g. hang

the tool on a tool belt when working at heights.

OPERATION AND MAINTENANCE

Remove the battery from the device before commencing

any activities related to installation, adjustment, repair or

maintenance.
MAINTENANCE AND STORAGE

•

Cleaning the device after each use is recommended.
