GRAPHITE Energy+ 58g012 - Инструкция по эксплуатации - Страница 14

14

Graphite Energy+ System Charger

Parameter

Value

Charger type

58G002

Supply voltage

230 V AC

Power supply frequency

50 Hz

Charging voltage

22 V DC

Max. charging current

2300 mA

Ambient temperature range

4

0

C – 40

0

C

Charging time of the battery 58G001

1 h

Charging time of the battery 58G004

2 h

Protection class

II

Weight

0,300 kg

Year of production

2017

N O I S E  L E V E L  A N D V I B R AT I O N  PA R A M E T E R S

Noise and vibration information

Parameters of produced noise level, such as sound pressure level
Lp

A

 and sound power level Lw

A

 with measurement uncer tainty K

are specified below in this manual, in compliance with EN 60745.
Vibration values a

h

 and measurement uncer tainty K are

determined in accordance with EN 60745-2-2 and specified
below.
Vibration level specified below in this manual was measured in
accordance with measurement procedure defined in EN 60745
and can be used to compare power tools. It can also be used for
initial assessment of exposure to vibrations.
Specified vibration level is representative for main applications
of the power tool. Vibration level may change if the power tool is
used for other purposes, with different working tools or will not
be maintained properly. The abovementioned factors may lead
to higher exposure to vibrations during whole working time.
To precisely define exposure to vibrations, include periods when
the power tool is switched off and when it is switched on but
not used for working. This way total exposure to vibrations may
be significantly lower. Use additional safety measures to protect
the user against results of exposure to vibrations, such as: power
tool and working tool maintenance, proper hand temperature
conditions, good work organisation.

Sound pressure level: Lp

A

= 95,1 dB (A) K=3dB (A)

Sound power level: Lw

A

= 106,1  dB (A) K=3dB (A)

Vibration acceleration: a

h

= 15,87 m/s

2

  K = 1,5 m/s

2

ENVIRONMENTAL PROTECTION / CE

Electrical equipment must not be disposed off
with household waste and, instead, should be
utilized at appropriate facilities. Information
on utilization can be provided by the product
vendor or the local authorities. Waste electrical
and electronic equipment contains substances
that are not neutral to the natural environment.
Equipment that is not recycled constitutes a
potential hazard to the environment and to
human health.

Li-Ion

Storage batteries/batteries must not be disposed
with domestic waste, put in a fire or into the
water. Damaged or used up storage batteries
must be properly recycled in compliance with the
current directive pertaining to disposal of storage
batteries and batteries.

* Right to introduce changes is reser ved.

“Grupa Topex Spółka z ograniczoną odpowiedzialnością” Spółka
komandytowa with seat in Warsaw at ul. Pograniczna 2/4 (hereinafter Grupa
Topex) informs, that all copyrights to this instruction (hereinafter Instruction),
including, but not limited to, text, photographies, schemes, drawings
and layout of the instruction, belong to Grupa Topex exclusively and are
protected by laws accordingly to Copyright and Related Rights Act of 4
Februar y 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz. U. 2006
No 90 item 631 with later ammendments). Copying, processing, publishing,
modifications for commercial purposes of the entire Instruction or its par ts
without written permission of Grupa Topex are strictly forbidden and may
cause civil and legal liability.
