14
Counter-clockwise rotation
– set the switch (
5
) to the extreme
right position.
* In cer tain cases position of the switch related to rotation may be different
than specified. Please refer to graphic signs located on the switch or tool
body.
Safe position of the direction selector switch (
5
) is in the middle,
it prevents accidental star ting of the power tool.
•
Drill cannot be star ted, when the switch is in this position.
•
Use this position of the switch to change drills or bits.
•
Before star ting the tool make sure the position of the direction
selector switch (
5
) is correct.
Do not change direction of rotation when the drill spindle
is rotating.
C H A N G E O F G E A R
Gear switch (
4
) (
fig. H
) allows to increase the range of rotational
speed.
Gear I:
small speed range, big torque
Gear II:
greater speed range, small torque.
Set the gear switch in position appropriate for the works to
per form. When the switch is blocked and cannot be moved, turn
the spindle slightly.
Never change the gear switch position when the drill is
operating. It may damage the power tool.
Long lasting drilling at low rotational speed of the spindle
may cause motor overheating. Long lasting drilling at
low rotational speed of the spindle may cause motor
overheating.
H O L D E R
The drill provides convenient holder (
6
) that allows to e.g. hang
the tool on a tool belt when working at heights.
OPERATION AND MAINTENANCE
Remove the battery from the device before commencing
any activities related to installation, adjustment, repair or
maintenance.
M A I N T E N A N C E A N D S TO R AG E
•
Cleaning the device after each use is recommended.
•
Do not use water or any other liquid for cleaning.
•
Clean the tool with a dr y cloth or blow through with
compressed air at low pressure.
•
Do not use any cleaning agents or solvents, they may damage
plastic par ts.
•
Clean ventilation holes in the motor casing regularly to
prevent device overheating.
•
In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a
qualified person.
•
Always store the tool in a dr y place, beyond reach of children.
•
Store the device with the batter y removed.
Q U I C K R E L E A S E C H U C K R E P L AC E M E N T
Quick-release chuck is screwed onto spindle of the drill and
additionally secured with a screw.
•
Set the direction selector switch (
5
) in the middle position.
•
Open jaws of quick release chuck (
1
) and unscrew the fixing
screw (left-hand thread) (
fig. H
).
•
Install hexagonal key in the quick release chuck and tap the
other end of the key.
•
Unscrew the quick release chuck.
•
Installation of the quick release chuck is similar to
deinstallation, only the sequence of actions is reversed.
All defects should be repaired by ser vice workshop authorized
by the manufacturer.
TECHNICAL PARAMETERS
R AT E D PA R A M E T E R S
Cordless drill
Parameter
Value
Battery voltage
18 V DC
Range of idle rotational speed
gear I
0-350 min
-1
gear II
0-1250 min
-1
Range of quick release chuck
2 -13 mm
Torque control range
1 – 19 +
drilling
Max. torque (soft drive)
35 Nm
Max. torque (hard drive)
55 Nm
Protection class
III
Weight
1,3 kg
Year of production
2017
Graphite Energy+ System Battery
Parameter
Value
Battery
58G001
58G004
Battery voltage
18 V DC
18 V DC
Battery type
Li-Ion
Li-Ion
Battery capacity
2000 mAh
4000 mAh
Ambient temperature range
4
0
C – 40
0
C
4
0
C – 40
0
C
Charging time for charger 58G002
1 h
2 h
Weight
0,400 kg
0,650 kg
Year of production
2017
2017
Graphite Energy+ System Charger
Parameter
Value
Charger type
58G002
Supply voltage
230 V AC
Power supply frequency
50 Hz
Charging voltage
22 V DC
Max. charging current
2300 mA
Ambient temperature range
4
0
C – 40
0
C
Charging time of the battery 58G001
1 h
Charging time of the battery 58G004
2 h
Protection class
II
Weight
0,300 kg
Year of production
2017
N O I S E L E V E L A N D V I B R AT I O N PA R A M E T E R S
Noise and vibration information
Parameters of produced noise level, such as sound pressure level
Lp
A
and sound power level Lw
A
with measurement uncer tainty K
are specified below in this manual, in compliance with EN 60745.
Vibration values a
h
and measurement uncer tainty K are
determined in accordance with EN 60745-2-1 and specified
below.
