12

• Do not expose the battery to fire or excessive temperature.

Exposure to fire or temperature above 130°C may cause explosion.

CAUTION!

 Temperature of 130°C can be also defined as 265°F.

• Observe all charging instructions. Do not charge the

battery in temperature outside of range defined in the
rating data table from the instruction manual.

Incorrect

charging or charging in temperature outside of defined range
may damage the batter y and increase the risk of fire.

BAT TERY REPAIRS

• Do not repair damaged batteries.

 Batter y can be repaired

only by the manufacturer or in an authorised workshop.

• When disposing of the worn out battery, take it to a service

point where you can utilize such dangerous wastes.

S A F E T Y  R E G U L AT I O N S  F O R T H E  C H A R G E R

• Do not expose the charger to humidity or water.

 Ingress of

water into the charger increases risk of electric shock. Use the
charger only in dr y rooms.

•

Disconnect the charger from power supply before star ting any
maintenance or cleaning.

• Do not use the charger when placed on flammable

sur face (e.g. paper, textiles) or in proximity of flammable
substance.

Greater charger temperature when charging

increases risk of fire.

• Check condition of the charger, cable and plug before each

use. Do not use the charger if any damage is found. Do not
try to disassemble the charger.

All repairs should be made at

an authorized ser vice workshop. Improper charger assembly may
cause electric shock or fire.

•

Children or persons who are physically, emotionally or
mentally disabled and other persons, whose experience or
knowledge is insufficient to use the charger while following all
safety rules should not use the charger without super vision of
person responsible for their safety. Other wise there is a risk of
improper use and injuries in consequence.

• When the charger is not in use, it should be disconnected

from the mains network.

• Observe all charging instructions. Do not charge the

battery in temperature outside of range defined in the
rating data table from the instruction manual.

Incorrect

charging or charging in temperature outside of defined range
may damage the batter y and increase the risk of fire.

CHARGER REPAIRS

• Do not repair damaged charger.

The charger can be repaired

only by the manufacturer or in an authorised workshop.

• When disposing of the worn out charger, take it to a service

point where you can utilize such wastes.

CAUTION! This device is designed to operate indoors.

The design is assumed to be safe, protection measures and
additional safety systems are used, never theless there is
always a small risk of injuries at work.

Li-Ion batteries may leak, set on fire or explode when
heated to high temperature or shor t-circuited. Do not store
the batteries in a car in hot and sunny days. Do not open
the battery. Li-Ion batteries contain electronic protection
devices that, if damaged, may cause fire or explosion of the
battery.

Explanation of used symbols

1

2

3

4

7

5

Max.

50°C

6

8

9

10

11

1.

Read instruction manual, obser ve warnings and safety
conditions therein.

2.

Use protective goggles and hearing protectors.

3.

Keep the tool away from children.

4.

Protect against rain.

5.

Use indoors, protect from water and moisture.

6.

Recycling.

7.

Protection class 2.

8.

Segregated waste collection.

9.

Do not throw cells into fire.

10.

Hazardous to water environment.

11.

Do not allow to heat above 50°C.

CONSTRUC TION AND USE

Drill is a batter y powered tool. Drive consists of a DC commutator
motor with permanent magnets and planetar y gear. Drill is
designed for screwing in and out screws and bolts in wood,
metal, plastics and ceramics, and for drilling holes in these
materials. Cordless, batter y-powered power tools are especially
useful for works in interior furnishing, adaptation of premises
etc.

Use the power tool in accordance with the manufacturer ’s
instructions only.

D E S C R I P T I O N  O F  D R AW I N G  PAG E S

Below enumeration refers to the device elements depicted on
the drawing pages of this manual.

1.

Quick-release chuck

2.

Ring of the quick release chuck

3.

Torque adjustment ring

4.

Gear switch

5.

Direction selector switch

6.

Holder

7.

Batter y

8.

Batter y lock button

9.

Switch

10.

Lighting

11.

LED diodes

12.

Charger

13.

Button for batter y level indication

14.

Batter y level indicator (LED)

* Differences may appear between the product and drawing.
