D U R A D R I V E

17

GB

Attach  the  depth  stopper  on  the  bit  (see  figure

[4b]

.

By  means  of  jamming  the  depth  stopper  with

the  bit  and  concurrent  pulling,  it  is  possible  to

pull out the bit.
Then attach a new bit in the holder.

9

Working with the machine

9.1

On/Off switch [1-2]

Pressing only the switch

[1-2]

 does not start the

machine –

it is not a machine fault

!

Upon screwing to the required depth, the power

tool switches off!

The machine can be switched on by means of sev-

eral methods:

a)

Set the forward / reverse switch

[1-3]

 into ma-

chine clockwise operation.
Set the switch

[1-4]

 into MAN position.

In  order  to  switch  on  the  power  tool,  apply  the

switch

[1-2]

  and  concurrently  press  the  bit  on

the screw.

Use  the  switch

[1-2]

  to  gradually  regulate  the

speed.

b)

Set the forward / reverse switch

[1-3]

 into ma-

chine clockwise operation.
Set the switch

[1-4]

 into AUTO position.

Press  the  bit  on  the  screw  and  the  power  tool

will switch on.

Switch

[1-2]

  does  not  need  to  be  pressed.  Maxi-

mum speed is set automatically.

b)

Set the forward / reverse switch

[1-3]

 into ma-

chine anti-clockwise operation.
In order to start the power tool, press the switch

[1-2]

The switch MAN/AUTO

[1-4]

 is in any position.

Use  the  switch

[1-2]

  to  gradually  regulate  the

speed.

If  the  forward  /  reverse  switch  is  set  to  anti-

clockwise  operation,  the  screwdriver  can  be

started only by pressing the switch

[1-2]

 without

additional pressure on the bit.
It is not necessary to remove the depth stopper

in order to unscrew screws.

9.2

Depth stop

Turning the depth stopper

[1-5]

 sets the screwing

depth – see figure

[5]

. The setting accuracy is ap-

prox ± 0,1 mm.

Upon setting the depth, set some screws to test and

adjust the depth.

Depth stop assembly

Fit the depth stop

[4-1]

 on the gear box

[4-5]

.

Press until it engages in the groove.

Depth stop disassembly

Remove  the  depth  stop  from  the  gear  box  by

pulling it.

9.3

Scaffolding holder and belt clip

Use  the  belt  clip

[6-1]

  to  temporarily  attach  the

screwdriver on the working clothing – it can be at-

tached by means of a screw

[6-2]

 to the left or right

of the power tool, and it is suitable for right and left

handed people – see figure

[6]

The  screwdriver  is  equipped  with  a  scaffolding

holder

[7-1]

 which is used for occasional machine

suspension. It can be attached to the left or right of

the power tool, by means of a screw

[7-2]

 – see fig-

ure

[7]

.

9.4

Magazine attachment

The magazine attachment enables to work contin-

uously, without unnecessary delays.

Fitting the magazine attachment

At first remove the depth stopper

[4-1]

 and bit,

bit holder

[4-2]

 as specified in chapter 8.

Set the switch

[1-4]

 into MAN position.

Push the long bit

[8-1]

 completely to the hexag-

onal spindle opening

[4-4]

.

Then  fit  the  magazine  attachment  on  the  gear

box. Push the attachment until it engages in the

groove of the gear box.
The attachment can be mounted at 30° steps.

Removing the magazine attachment

Use  power  to  carefully  pull  the  magazine  at-

tachment from the gear box.

Setting the screw length

Press  button

[9-1]

  to  remove  and  insert  the

depth  stop

[9-2]

  and  set  the  required  screw

length.

Anti-clockwise

rotation

screws are inserted deeper

Clockwise rotation screws are inserted to lower

depth
