16

D U R A D R I V E

GB

5

Machine features

Accessories shown or described are sometimes not

included in the scope of delivery.
The specified illustrations appear at the beginning

of the Operating Instructions.

6

Operation

6.1

Charger cable holder [3-2]

Unwind the cable completely from the recess

before using the charger.

6.2

Changing the battery pack

Inserting the battery pack [2 A]
Removing the battery pack[2 B]

Battery pack is ready for use immediately upon

delivery and can be charged at any time.

6.3

Charging the battery pack [3]

The LED

[3-1]

 on the charger indicates the respec-

tive operating status of the charger.

7

Settings

7.1

Changing direction of rotation [1-3]

• Switch to the left = clockwise rotation
• Switch to the right = counterclockwise rotation

8

Tool holder, attachments

8.1

Bit holder

The bit holder is used for fast replacement of bits.

Bit holder assembly

Set the switch

[1-4]

 into MAN position.

Set the bit holder

[4-2]

 completely to the hexag-

onal spindle opening

[4-4]

.

Attach bit into the holder

[4-3]

.

Then attach  the depth stopper on the gear box

as specified in chapter 9.2.

Bit holder disassembly

Remove the depth stopper as specified in chap-

ter 9.2.
Use power to pull out the holder from the spin-

dle opening.

8.2

Bit replacement

You can use the depth stopper

[1-6]

 for the bit re-

placement

[1-5]

.

[1-1]

Bit store

[1-2]

On/Off switch

[1-3]

Right/left switch

[1-4]

AUTO/MAN switch

[1-5]

Depth stop

[1-6]

Bit

[1-7]

Insulated gripping surfaces (grey shaded

area)

[3-1]

LED-Display

[3-2]

Cable holder

[3a]

Wall mount for charger

LED yellow - lit continuously

Charger is ready to use.

LED green - flashes quickly

Battery pack is charged to maxi-

mum capacity.

LED green - flashes slowly

Battery pack is charged with

reduced current. Li-ion is

charged to 80 %.

LED green - lit continuously

Charging is complete or is not

restarted as current charge sta-

tus is greater than 80%.

LED red - flashes

General fault indication, e.g.

incomplete contact, short circuit,

defective battery pack, etc.

LED red - lit continuously

Battery temperature is outside

the permitted range.

CAUTION

Risk of injury

Always switch off the power tool before adjusting

settings!

WARNING

Risk of injury

Always disconnect  the battery pack  before per-

forming any type of work on the machine!

CAUTION

Hot and sharp tools
Risk of injury

Do not use insert tools that are blunt or defec-

tive.
Wear protective gloves.
