class II insulation according to European Standard EN

60745.  Radio  interference  suppression  complies  with  the

European Standard EN 60745.

3. Auxiliary handle

WARNING!

Operate your machine only with the

auxiliary handle.

-  Unscrew  the  auxiliary  handle

H

 in an anticlockwise

direction.

-  Turn the auxiliary handle

H

 to the required position.

-  Screw the auxiliary handle

H

 in place again.

4. Setting the depth gauge

-  Make sure before you start that drill-bit is inserted.

-  Hold  the  bit  tip  against  the  work  surface.  Push  the

depth gauge against the work surface, to the same depth

as the length of the bit.

-  Read the value in mm off the scale on the depth gauge

and subtract the required drill depth.

START UP

1. Reversing the Rotational Direction.

The rotational direction switch

I

 is used to reverse the

rotational  direction  of  the  machine.  However,  this  is  not

possible with the On/Off switch

J

 actuated.

Right rotation: For drilling and driving in screws, push

the rotational direction switch

I

 downward on the left side

and at the same time upward on the right side.

Left  rotation:  For  loosening  and  unscrewing  screws

and nuts, push the rotational direction switch

I

 upward on

the left side and at the same time downward on the right

side.

2. Switching On and Off

To start the machine, press the On/Off switch

J

 and

keep  it  pressed.  To  lock  the  pressed  On/Off  switch

J

,

press the lock-on button

K

.  To  switch  off  the  machine,

release the On/Off switch

J

 or when it is locked with the

lock-on button

K

,  briefly  press  the  On/Off  switch

J

 and

then release it.

3. Adjusting the Speed

The  speed  of  the  switched  on  power  tool  can  be

variably adjusted, depending on how far the On/Off switch

J

 is pressed.

Light pressure on the On/Off switch

J

 results in a low

rotational speed. Further pressure on the switch results in

an increase in speed.

4. Preselecting the Speed

  With the thumbwheel for speed preselection

F

,

the required speed can be preselected even during

operation.

The  required  speed  depends  on  the  material  and

the working conditions, and can be determined through

practical testing.

5. Setting the Operating Mode (mod. DI16/850GE2)

Drilling

.

Set the selector switch

A

 to the “Drilling” symbol.

Impact Drilling

.

  Set the selector switch

A

 to the “Impact drilling”

symbol.

Two  speed  ranges  can  be  preselected  with  the  gear

selector

G

.

Gear I:

Low speed range; for working with large drilling.

Gear II:

  High speed range; for working with small drilling

diameter.

Note.

 If the gear selector

 G

 cannot be fully engaged,

lightly rotate the drive spindle with the drill bit by twisting the

drill chuck.

OPERATION

Drilling.

-  Fit the drill.

-  Place the drill against the material before switching

it on, press it until the lengthways play is taken up, then

switch on and work exerting light pressure (e.g. 30N).

Note!

 Exerting greater pressure does not increase the

machine’s effectiveness!

-  Take  the  drill  out  of  the  hole  from  time  to  time  to

remove dust.

NOISE AND VIBRATION

This  tool  has  been  designed  and  made  to  reduce

noise  to  a  minimum.  However,  in  spite  of  this,

in certain

circumstances the maximum noise level in the place of

work could exceed 85 dBA. In this case, the operator

should wear ear protection.

The machine’s noise and vibration levels, measured in

compliance with EN60745, usually reach:

D13/700GE

D16/850GE

DI16/850GE2

Noise values

Sound pressure level

LpA

81.7 dB(A)

79.1 dB(A)

87.6 dB(A)

Sound power level

LWA

92.7 dB(A)

90.1 dB(A)

98.6 dB(A)

Uncertainty K

3 dB(A)

3 dB(A)

3 dB(A)

Vibration values

Drilling into metal, a

h,D

3.352 m/s²

3.417 m/s²

3.919 m/s²

Impact drilling into

concrete, a

h,ID

--

--

11.403 m/s²

Uncertainty K

1.5 m/s²

1.5 m/s²

1.5 m/s²

Use ear protection!

WARNING!

  The  vibration  level  given  in  these

instructions has been measured in accordance with

a  standardized  measurement  procedure  specified  in

EN60745  and  can  be  used  to  compare  devices.  Different

uses of the device give rise to different vibration levels and

in many cases they may exceed the values given in these

instructions.  It  is  easy  to  underestimate  the  vibration  load

if the electrical power tool is used regularly in particular

circumstances.

Note.

 If you wish to make an accurate assessment of

the vibration loads experienced during a particular period of

working , you should also take into account the intervening

periods of time when the device is switched off or is running

but is not actually in use. This can result in a much lower

vibration load over the whole of the period of working.

ACCESSORIES

  Accessories and their corresponding order number

can be found in our catalogues.

MAINTENANCE AND CARE

WARNING!

Always unplug the machine before

carrying out work on it.

-  The  machine  should  be  taken  to  a  technical  service

centre if the power falls.
