32

EnGLIsh

DCF902

Precision Wrench™ Mode

Precision Wrench™

Lo Mode

Low Speed Impacting

Hi Mode

High Speed Impacting

Quick-Release Chuck (Fig. F)

DCF801

WARNING:

Use only impact accessories. Non-impact

accessories may break and cause a hazardous condition.
Inspect accessory prior to use to ensure that it con tains
no cracks.

nOTE:

The chuck accepts 6.35 mm hex bit tips only. Using

25 mm bits allows better access in tight spaces.
Place the forward/reverse button

 4

 in the locked off (centre)

position or remove battery pack before changing accessories.

To install an accessory,

 push accessory to fully insert into

chuck

 6

. The chuck collar

 5

 does not need to be pulled up to

lock accessory in place.

To remove an accessory,

 pull the chuck collar away from the

front of the tool. Remove the accessory and release the collar.

Anvil With Hog Ring (Fig. G)

DCF902

WARNING:

Use only impact accessories. Non-impact

accessories may break and cause a hazardous condition.
Inspect accessory prior to use to ensure that it contains
no cracks.

CAUTION:

Inspect anvils, detent pins, and hog rings prior

to use. Missing or damaged items should be replaced
before use.

Place the forward/reverse button

 4

 in the locked off (centre)

position or remove battery pack before changing accessories.
To install an accessory on the hog ring anvil, firmly push
accessory onto the anvil

 10

. The hog ring

 11

 compresses to

allow the accessory to slide on. After accessory is installed, the
hog ring applies pressure to help provide accessory retention.
To remove an accessory, grasp the accessory and firmly pull
it off.

Usage

Your impact tool generates the following maximum torque:

Cat #

Nm

Ft.-Lbs.

In.-Lbs

DCF801

163

120.8

1450

DCF902

168

125

1500

CAUTION:

Ensure fastener and/or system will withstand

the level of torque generated by the tool. Excessive torque
may cause breakage and possible personal injury.

1.  Place the accessory on the fastener head. Keep the tool

pointed straight at the fastener.

2.  Press switch to start operation. Release the switch to stop

operation. Always check torque with a torque wrench, as
the fastening torque is affected by many factors including
the following:

-

Voltage:

 Low voltage, due to a nearly discharged

battery, will reduce fastening torque.

-

accessory size:

Failure to use the correct accessory size

will cause a reduction in fastening torque.

-

Bolt size:

 Larger bolt diameters generally require

higher fastening torque. Fastening torque will also vary
according to length, grade, and torque coefficient.

-

Bolt:

 Ensure that all threads are free of rust and other

debris to allow proper fastening torque.

-

Material:

The type of material and surface finish of the

material will affect fastening torque.

-

Fastening Time:

 Longer fasten ing time results in

increased fastening torque. Using a longer fastening
time than recom mended could cause the fasteners to
be overstressed, stripped or damaged.

MAINTENANCE

Your

D

e

WALT

 power tool has been designed to operate

over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

 An accidental

start-up can cause injury.

The charger and battery pack are not serviceable.

Lubrication

Your power tool requires no additional lubrication.

Cleaning

WARNING:

 Blow dirt and dust out of the main housing

with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing this procedure.

WARNING:

Never use solvents or other harsh chemicals

for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into a liquid.

Optional Accessories

WARNING:

 Since accessories, other than those offered

by

D

e

WALT

, have not been tested with this product, use

of such accessories with this tool could be hazardous.
To reduce the risk of injury, only

D

e

WALT

 recommended

accessories should be used with this product.

Consult your dealer for further information on the
appropriate accessories.
