10

CORDLESS DRILL

EN

ATTENTION!

Do not switch speed until the spindle stops. Always send the switch 3 key to the end, do not

leave it in an intermediate position. Failure to follow instructions may cause damage to the

gearbox.

Torque adjustment

Torque adjustment function allows you to choose the optimal force of tightening screws, depending on their size
and working conditions. The choice of the optimal tightening force is carried out empirically.
Change of the torque is carried out by setting ring 2 to the position indicated by the arrow located at the top of
the case.

•

positions 1-21 serve for screwing in / out screws, however, a higher number corresponds to a higher torque;

•

position   is for drilling, wherein torque adjustment function is blocked.

NOTE. Numeric values indicated on the ring 2 (pic. 1) do not reflect torque values expressed in Nm, and indicate
the ordinal position of the adjustment ring.

Light of the working area

LED light of working area turns on simultaneously with the engine when you press the switch key.

Replacement of tooling

ATTENTION!

Before changing the tooling, remove the battery from the tool or set the switch of the direction

of rotation to the middle position to prevent accidental activation of the tool and injury.

To open the chuck, turn the outer ring of its sleeve counterclockwise (when viewed from the front) until the tool
shank is positioned freely between the chuck jaws.
Install the tooling into the chuck. Use a tooling with a cylindrical or hex shank with a diameter of 0.8 to 10 mm.
Tooling with a shank less than 0.8 mm cannot be properly centered in this chuck.
Clamp the chuck by turning its outer ring clockwise.
Make a trial tool enable, to make sure that the tooling is installed and centered.

NOISE AND VIBRATION

Noise and vibration characteristics are given in the table №1.
However, if the drill/driver will be used for other work with the use of working tools, not provided by the
manufacturer, or maintenance will not meet the requirements, then the vibration and noise level may be different.

ATTENTION!

Always use personal hearing protection.
