English |
15
Bosch Power Tools
1 609 92A 1RB | (22.1.16)
3
Depth stop
4
Auxiliary handle (insulated gripping surface)
5
Intermediate piece of auxiliary handle
6
Wing bolt for depth stop adjustment
7
Torque presetting ring
8
Mode selector switch
9
Gear selector
10
Colour clip
11
Belt clip
12
Battery pack
13
Battery unlocking button
14
Worklight
15
Overload protector indicator
16
Universal bit holder *
17
Rotational direction switch
18
On/Off switch
19
Handle (insulated gripping surface)
* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Sound emission values determined according to
EN 60745-2-1, EN 60745-2-2.
GSR 14,4 VE-EC / GSR 18 VE-EC
Typically the A-weighted sound pressure level of the product is less than 70 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Cordless Drill/Driver
Combination Cordless Drill
GSR 14,4 VE-EC
GSR 18 VE-EC
GSB 14,4 VE-EC
GSB 18 VE-EC
Article number
3 601 JF1 0..
3 601 JF1 1..
3 601 JF1 2..
3 601 JF1 3..
Rated voltage
V=
14.4
18
14.4
18
No-load speed
–
1st gear
–
2nd gear
min
-1
min
-1
0 – 420
0 – 1900
0 – 480
0 – 2100
0 – 420
0 – 1900
0 – 480
0 – 2100
Impact rate
min
-1
-
-
0 – 28500
0 – 31500
Max. torque for soft screwdriving applica-
tion according to ISO 5393
Nm
40
*
47
*
40
*
47
*
Maximum torque, hard screwdriving appli-
cation according to ISO 5393
Nm
70
*
75
*
70
*
75
*
Maximum drilling diameter (1st/2nd gear)
–
Wood
–
Steel
–
Brickwork
mm
mm
mm
68
13
-
82
13
-
68
13
14
82
13
16
Tool holder
1.5 – 13
1.5 – 13
1.5 – 13
1.5 – 13
Max. screw dia.
mm
10
12
10
12
Weight according to EPTA-Procedure
01:2014
kg
2.1*
2.2*
2.2*
2.3*
Permitted ambient temperature
–
during charging
–
during operation
**
and during storage
°C
°C
0... +45
-20... +50
0... +45
-20... +50
0... +45
-20... +50
0... +45
-20... +50
Recommended batteries
GBA 14,4V..
GBA 18V..
GBA 18V... W
GBA 14,4V..
GBA 18V..
GBA 18V... W
Recommended chargers
AL 18..
GAL 3680
AL 18..
GAL 3680
AL 18..
GAL 3680
AL 18..
GAL 3680
Recommended chargers for wireless charg-
ing batteries
GAL 18... W
GAL 18... W
*depending on the battery pack being used
** limited performance at temperatures < 0 ° C
