 English |

11

Bosch Power Tools

2 6

09 141 061 | (24.6.13)

Intended Use

The machine is intended for driving in and loosening screws

as well as for drilling in wood, metal, ceramics and plastic.

GSB machines are additionally intended for impact drilling in

bricks, brickwork and masonry.
The light of this power tool is intended to illuminate the power

tool’s direct area of working operation and is not suitable for

household room illumination.

Technical Data

The technical data of the machine are listed in the table on

page 155.

Declaration of Conformity

We declare under our sole responsibility that the product de-

scribed under “Technical Data” is in conformity with the fol-

lowing standards or standardisation documents: EN 60745

according to the provisions of the directives 2009/125/EC

(Regulation 1194/2012), 2011/65/EU, 2004/108/EC,

2006/42/EC.
Technical file (2006/42/EC) at:

Robert Bosch GmbH, PT/ETM9,

D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

29.04.2013

Noise/Vibration Information

The measured values of the machine are listed in the table on

page 155.
Noise and vibrational values (vector sum of three directions)

determined according to EN 60745.
The vibration emission level given in this information sheet has

been measured in accordance with a standardised test given

in EN 60745 and may be used to compare one tool with anoth-

er. It may be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may signif-

icantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep hands warm, organise work patterns.

Mounting and Operation

Maintenance and Cleaning



For safe and proper working, always keep the machine

and ventilation slots clean.

Clean the application tool, the tool holder, the power tool’s

ventilations slots, and the battery’s ventilation slots each time

after using.

After-sales Service and Application

Service

Our after-sales service responds to your questions concern-

ing maintenance and repair of your product as well as spare

parts. Exploded views and information on spare parts can al-

so be found under:

www.bosch-pt.com

Bosch’s application service team will gladly answer questions

concerning our products and their accessories.
In all correspondence and spare parts order, please always in-

clude the 10-digit article number given on the type plate of

the machine.

Great Britain

Robert Bosch Ltd. (B.S.C.)

P.O. Box 98

Broadwater Park

North Orbital Road

Denham

Uxbridge

UB 9 5HJ

Tel. Service: (0844) 7360109

Fax: (0844) 7360146

E-Mail: boschservicecentre@bosch.com

Henk Becker
Executive Vice President

Engineering

Helmut Heinzelmann
Head of Product Certification

PT/ETM9

Action

Figure

Page

Removing the battery

1

156

Inserting the battery

2

156

Checking the battery charge

condition

3

156

Assembling/Dismantling auxiliary

handle

4

157

Changing the position of the auxiliary

handle

5

157

Mounting application tools

6

157

Adjusting the drilling depth

X

7

158

Reversing the rotational direction

8

159

Setting the torque

9

159

Selecting the drilling position

10

160

Setting the operating mode

11

160

Gear selection, mechanical

12

160

Switching On and Off

13

161

Selecting Accessories

–

162
