18

 | English

2 609 140 533 | (20.11.07)

Bosch Power Tools

Changing the Tool

Keyless Chuck (see figure B)

Hold the rear sleeve

3

 of the keyless chuck

1

tight and turn the front sleeve

2

 in rotation di-

rection

n

, until the tool can be inserted. Insert

the tool.
Hold the rear sleeve

3

 of the keyless chuck

1

tight and firmly turn the front sleeve

2

 in rota-

tion direction

o

 by hand until the locking action

is no longer heard. This automatically locks the
drill chuck.
The locking is released again to remove the tool
when the front sleeve

2

 is turned in the opposite

direction.

Key Type Drill Chuck (see figure C)

f

Wear protective gloves when changing the
tool.

The drill chuck can become very hot

during longer work periods.

Open the key type drill chuck

14

 by turning until

the tool can be inserted. Insert the tool.
Insert the chuck key

13

 into the corresponding

holes of the key type drill chuck

14

 and clamp

the tool uniformly.

Screwdriver Tools (see figure D)

When working with screwdriver bits

16

, a uni-

versal bit holder

15

 should always be used. Use

only screwdriver bits that fit the screw head.
For driving screws, always position the “Drill-
ing/Impact Drilling” selector switch

4

 to the

“Drilling” symbol.

Replacing the Drill Chuck

Removing the Drill Chuck (see figure E)

To dismount the keyless chuck

1

, clamp an Allen

key

17

 into the keyless chuck

1

 and position an

open-end spanner

18

 (size 14 mm mm) against

the spanner flats of the drive spindle. Place the
machine on a firm support, e.g., a workbench.
Hold the open-end spanner

18

 firmly and loosen

the keyless chuck

1

 by turning the Allen key

17

in rotation direction

n

. Loosen a tight seated

keyless chuck by giving the long end of the Allen
key

17

 a blow. Remove the Allen key from the

keyless chuck and completely unscrew the key-
less chuck.
The key type drill chuck

14

 is removed in the

same manner as the keyless chuck.

Mounting the Drill Chuck (see figure F)

The keyless chuck/key type drill chuck is mount-
ed in reverse order.

The drill chuck must be tightened with a
tightening torque of approx. 30 – 35 Nm.

Dust/Chip Extraction

f

Dusts from materials such as lead-containing
coatings, some wood types, minerals and
metal can be harmful to one’s health. Touch-
ing or breathing-in the dusts can cause aller-
gic reactions and/or lead to respiratory infec-
tions of the user or bystanders.
Certain dusts, such as oak or beech dust, are
considered as carcinogenic, especially in
connection with wood-treatment additives
(chromate, wood preservative). Materials
containing asbestos may only be worked by
specialists.
– Use dust extraction whenever possible.
– Provide for good ventilation of the work-

ing place.

– It is recommended to wear a P2 filter-

class respirator.

Observe the relevant regulations in your
country for the materials to be worked.

Operation

Starting Operation

f

Observe correct mains voltage! The voltage
of the power source must agree with the
voltage specified on the nameplate of the
machine. Power tools marked with 230 V
can also be operated with 220 V.
