Noise/Vibration Information

Measured values determined according to
EN 60745.
Typically the A-weighted noise levels of the
product are: Sound pressure level 93 dB(A);
Sound power level 104 dB(A). Uncertainty
K = 3 dB.

Wear hearing protection!

Vibration total values (triax vector sum) deter-
mined according to EN 60745:
Drilling into metal: Vibration emission value
a

h

= 3 m/s

2

, Uncertainty K = 1.5 m/s

2

,

Impact drilling into concrete: Vibration emission
value a

h

= 26 m/s

2

, Uncertainty K = 3 m/s

2

,

Screwdriving: Vibration emission value
a

h

< 2.5 m/s

2

, Uncertainty K = 1.5 m/s

2

.

The vibration emission level given in this infor-
mation sheet has been measured in accordance
with a standardised test given in EN 60745 and
may be used to compare one tool with another.
It may be used for a preliminary assessment of
exposure.
The declared vibration emission level repre-
sents the main applications of the tool. However
if the tool is used for different applications, with
different accessories or poorly maintained, the
vibration emission may differ. This may signifi-
cantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibra-
tion should also take into account the times
when the tool is switched off or when it is run-
ning but not actually doing the job. This may sig-
nificantly reduce the exposure level over the to-
tal working period.
Identify additional safety measures to protect
the operator from the effects of vibration such
as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.

Declaration of Conformity

We declare under our sole responsibility that
the product described under “Technical Data” is
in conformity with the following standards or
standardization documents: EN 60745 accord-
ing to the provisions of the directives
2004/108/EC, 98/37/EC (until Dec. 28, 2009),
2006/42/EC (from Dec. 29, 2009 on).
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen

06.11.2007, Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

Assembly

f

Before any work on the machine itself, pull
the mains plug.

Auxiliary Handle (see figure A)

f

Operate your machine only with the auxilia-
ry handle 11.

The auxiliary handle

11

 can be set to any posi-

tion for a secure and low-fatigue working pos-
ture.
Turn the wing bolt for adjustment of the auxilia-
ry handle

10

 in anticlockwise direction and set

the auxiliary handle

11

 to the required position.

Then tighten the wing bolt

10

 again in clockwise

direction.

Adjusting the Drilling Depth (see figure A)

The required drilling depth

X

 can be set with the

depth stop

12

.

Press the button for the depth stop adjustment

9

 and insert the depth stop into the auxiliary

handle

11

.

Pull out the depth stop until the distance be-
tween the tip of the drill bit and the tip of the
depth stop correspond with the desired drilling
depth

X

.

Dr. Egbert Schneider
Senior Vice President
Engineering

Dr. Eckerhard Strötgen
Head of Product
Certification
