16

 | English

2 609 140 533 | (20.11.07)

Bosch Power Tools

f

Always wait until the machine has come to
a complete stop before placing it down.

The

tool insert can jam and lead to loss of control
over the power tool.

f

Never use the machine with a damaged ca-
ble. Do not touch the damaged cable and
pull the mains plug when the cable is dam-
aged while working.

Damaged cables in-

crease the risk of an electric shock.

Functional Description

Read all safety warnings and all in-
structions.

Failure to follow the

warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.

Intended Use

The machine is intended for impact drilling in
brick, concrete and stone as well as for drilling
in wood, metal and plastic. Machines with elec-
tronic control and right/left rotation are also
suitable for screwdriving and thread-cutting.

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.

1

Keyless chuck *

2

Front sleeve

3

Rear sleeve

4

“Drilling/Impact Drilling” selector switch

5

Lock-on button for On/Off switch

6

On/Off switch

7

Thumbwheel for speed preselection
(not for machine version 3 601 B17 103)

8

Rotational direction switch

9

Button for depth stop adjustment

10

Wing bolt for adjustment of auxiliary handle

11

Auxiliary handle *

12

Depth stop *

13

Chuck key *

14

Key type drill chuck *

15

Universal bit holder *

16

Screwdriver bit *

17

Allen Key **

18

Open-end spanner **

* The accessories illustrated or described are not in-
cluded as standard delivery.

** Commercially available (not included in the deliv-
ery scope)

Technical Data

Impact Drill

GSB 13 RE

Professional

Article number

3 601 B17 1..

Rated power input

W

600

Output power

W

301

No-load speed

rpm

0

– 2 800

Rated speed

rpm

1 570

Impact rate

bpm

25 070

Rated torque

Nm

1.8

Right/left rotation

z

Spindle collar dia.

mm

43

Max. drilling dia.
– Brickwork
– Concrete
– Steel
– Wood

mm
mm
mm
mm

15
13
10
25

Chuck clamping range

mm

1.5

– 13

Weight according to
EPTA-Procedure
01/2003

kg

1.8

Protection class

/

II

The values given are valid for nominal voltages [U] of
230/240 V. For lower voltage and models for specific
countries, these values can vary.

Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.
