Safety Warnings for Working without Drill Stand



Use auxiliary handle(s), if supplied with the tool.

Loss

of control can cause personal injury.



When working with the machine, always hold it firmly

with both hands and provide for a secure stance.

The

power tool is guided more secure with both hands.



Always wait until the machine has come to a complete

stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.



If the application tool should become blocked, switch

the machine off. Loosen the application tool.



Before switching on the power tool, make sure that the

application tool moves freely.

When switching on with a

blocked drilling tool, high torque reaction can occur.

Safety Warnings for Working with Drill Stand



Never leave the machine before it has come to a com-

plete stop.

Cutting tools that are still running can cause in-

juries.

Safety Warnings for Wet Drilling



Never operate the machine without the portable resid-

ual current device (PRCD) provided.

Products sold in GB only: Never operate the 110 V exe-

cution of the machine without isolation transformer ac-

cording to EN/IEC 61558-1 and EN/IEC 61558-2-23.

The isolation transformer must have a grounded earth

wire on the secondary winding side.



Before starting work, check the proper function of the

portable residual current device (PRCD). Have a dam-

aged portable residual current device (PRCD) repaired

or replaced by your Bosch after-sales service agent.



Pay attention that neither persons in the working area

nor the power tool itself come into contact with the wa-

ter that comes out.

When wet drilling over-

head, the escaping water

must be collected.

To do

this, insert the power tool in-
to a drill stand and mount a
water collecting ring (see
“Accessories/Spare Parts”,
page 15).



Ensure that water-carrying hoses, connectors and the

water collection ring (accessory) are in immaculate

condition. Replace damaged or worn parts before the

next use.

Water escaping from parts of the power tool will

increase the risk of electric shock.

Product Description and

Specifications

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

In conjunction with diamond wet-drilling core bits and a water
supply, the power tool is intended for wet drilling in concrete
and reinforced concrete. The power tool can be combined
with an extraction device (water collection ring and wet/dry
vacuum cleaner).

In conjunction with dry diamond core bits and a suitable ex-
traction device, the machine is intended for dry drilling in
bricks, sandstone, aerated concrete and tiles.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

On/Off switch

2

Lock-on button for On/Off switch

3

Portable residual current device (PRCD)

4

Vacuum hose *

5

Vacuum connection *

6

Extraction adapter

7

Water connection adapter

8

Water outlet connector

9

Water cock

10

Gear selector

11

Claw coupling

12

Auxiliary handle (insulated gripping surface)

13

Handle (insulated gripping surface)

14

Core bit *

15

Drill spindle

16

Wing bolt for adjustment of auxiliary handle

17

Spirit level for horizontal alignment

18

Spirit level for vertical alignment

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Diamond Drill

GDB 180 WE

Article number

3 601 A89 8..

Rated power input

W

2 000

Output power

W

1 340

Rated speed n

0

– 1st  gear
– 2nd  gear

min

-1

min

-1

900

2 800

Drilling diameter
– optimum in brickwork
– possible in brickwork
– optimum  in  concrete
– possible  in  concrete

mm
mm
mm
mm

40 – 180

0 – 180

40 – 150

0 – 180

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
