12

 | English

2 609 140 656 | (21.7.11)

Bosch Power Tools

Product Description and Specifica-

tions

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

While reading the operating instructions, unfold the graphics

page for the machine and leave it open.

Intended Use

The machine is intended for drilling in wood, metal, ceramic

and plastic. Machines with electronic control and right and

left rotation are also suitable for screwdriving and tapping.

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1

Keyless chuck

2

Front sleeve

3

Rear sleeve

4

Belt clip

5

Lock-on button for On/Off switch

6

On/Off switch

7

Rotational direction switch  (GBM 10 RE)

8

Handle (insulated gripping surface)

9

Screwdriver bit *

10

Universal bit holder *

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Technical Data

Noise/Vibration Information

Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:

Sound pressure level 83 dB(A); Sound power level 94 dB(A).

Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:

Drilling into metal: a

h

= 5.0 m/s

2

, K = 1.5 m/s

2

,

Screwdriving: a

h

= 3.0 m/s

2

, K = 1.5 m/s

2

.

The vibration emission level given in this information sheet

has been measured in accordance with a standardised test

given in EN 60745 and may be used to compare one tool with

another. It may be used for a preliminary assessment of expo-

sure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working pe-

riod.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work pat-

terns.

Rotary drill

GBM 10

Professional

GBM 10 RE

Professional

Article number

3 601 D73 1..

3 601 D73 6..

Rated power input

W

600

600

Output power

W

360

360

No-load speed

min

-1

2 600

0 – 2 600

Rated speed

min

-1

1 676

1 676

Rated torque

Nm

20

20

Spindle collar dia.

mm

43

43

Speed control

z

Right/left rotation

z

Max. drilling dia.

– Steel

– Wood

– Aluminium

mm

mm

mm

10

25

10

10

25

10

Chuck clamping range

mm

1 – 10

1 – 10

Weight according to EPTA-Procedure 01/2003

kg

1.7

1.7

Protection class

/

II

/

II

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.

OBJ_DOKU-27517-001.fm  Page 12  Thursday, July 21, 2011  9:15 AM
