ENGLISH

♦

  Remove the chuck by turning it

counterclockwise.

♦

 To

re

fi

 t the chuck, screw it onto the spindle

and secure it with the chuck retaining screw.

Use

Warning!

Let the tool work at its own pace. Do

not overload.

Warning!

Before drilling into walls,

fl

 oors or

ceilings, check for the location of wiring and pipes.

Selecting the drilling mode

♦

  For hammer drilling in masonry and concrete,

set the operating mode selector (5) to the

position.

♦

  For drilling in steel, wood and plastics, set the

operating mode selector (5) to the   position.

Selecting the direction of rotation

For drilling and tightening screws, use forward
(clockwise) rotation. For loosening screws
or removing a jammed drill bit, use reverse
(counterclockwise) rotation.

♦

  To select forward rotation, push the forward/

reverse slider (4) to the left.

♦

  To select reverse rotation, push the forward/

reverse slider to the right.

Warning!

Never change the direction of rotation

while the motor is running.

Switching on and off

♦

  To switch the tool on, press the variable speed

switch (1). The tool speed depends on how far
you press the switch. If the tool has a variable
speed control knob (3), set it to the required
speed range. As a general rule, use low
speeds for large diameter drill bits and high
speeds for smaller diameter drill bits.

♦

  For continuous operation, press the lock-on

button (2) and release the variable speed
switch. This option is available only at full
speed or at any speed preset with the variable
speed control knob (3). This option does not
work in reverse rotation.

♦

  To switch the tool off, release the variable

speed switch. To switch the tool off when
in continuous operation, press the variable
speed switch once more and release it.

Accessories

The performance of your tool depends on
the accessory used. Black & Decker and
Piranha accessories are engineered to high
quality standards and designed to enhance

the performance of your tool. By using these
accessories you will get the very best from your
tool.

Maintenance

Your Black & Decker corded/cordless appliance/
tool has been designed to operate over a long
period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon
proper tool care and regular cleaning.

Warning!

Before performing any maintenance on

corded/cordless power tools:

♦

  Switch off and unplug the appliance/tool.

♦

  Or switch off and remove the battery from

the appliance/tool if the appliance/tool has
a separate battery pack.

♦

  Or run the battery down completely if it is

integral and then switch off.

♦

  Unplug the charger before cleaning it. Your

charger does not require any maintenance
apart from regular cleaning.

♦

  Regularly clean the ventilation slots in your

appliance/tool/charger using a soft brush or
dry cloth.

♦

  Regularly clean the motor housing using

a damp cloth. Do not use any abrasive or
solvent-based cleaner.

♦

  Regularly open the chuck and tap it to remove

any dust from the interior (when

fi

 tted).

Mains plug replacement
(U.K. & Ireland only)

If a new mains plug needs to be

fi

 tted:

♦

  Safely dispose of the old plug.

♦

  Connect the brown lead to the live terminal in

the new plug.

♦

  Connect the blue lead to the neutral terminal.

Warning!

No connection is to be made to the

earth terminal. Follow the

fi

 tting instructions

supplied with good quality plugs. Recommended
fuse: 5 A.

Protecting the environment

Separate collection. This product must
not be disposed of with normal household
waste.

Should you

fi

 nd one day that your Black & Decker

product needs replacement, or if it is of no further
use to you, do not dispose of it with household
waste. Make this product available for separate
collection.
