5

ENGLISH

(Original instructions)

Features (Fig. A)

1.  Variable speed switch

2.  Lock-on button

3.  Forward/reverse slider

4.  Drilling mode selector

5.  Chuck

6.  Depth stop

7.  Side handle

Additional safety instructions for

hammer drill

•  Wear ear protectors with impact drills.

Exposure to noise can cause hearing

loss.

•  Use auxiliary handles supplied with the

tool.

 Loss of control can cause personal

injury.

•  Hold power tool by insulated gripping

surfaces when performing an operation

where the cutting tool may contact

hidden wiring or its own cord.

 Contact

with a “live” wire will also make exposed

metal parts of the power tool “live” and

shock the operator.

•  Use clamps or another practical way to

secure and support the workpiece to a

stable platform.

 Holding the work by

hand or against your body leaves it

unstable and may lead to loss of control.

•  Before drilling into walls, floors or

ceilings check for the location of wiring

and pipes.

•  Avoid touching the tip of a drill bit just

after drilling, as it may be hot

Assambly

Warning!

 Before assembly, make sure that

the tool is switched off and unplugged.

Fitting the side handle and depth

stop (Fig. B)

Turn the grip counterclockwise until you can

slide the side handle (7) onto the front of

the tool as shown.

•  Rotate the side handle into the desired

position.

•  Insert the depth stop (6) into the

mounting hole as shown.

•  Set the drilling depth as described below.

•  Tighten the side handle by turning the

grip clockwise.

Fitting a drill bit or screwdriver bit

Keyed chuck (Fig. C)

•  Open the chuck by turning the sleeve (9)

counterclockwise.

•  Insert the bit shaft (8) into the chuck.

•  Insert the chuck key (10) into each hole

(11) in the side of the chuck and turn

clockwise until tight.

Removing and refitting the chuck

(Fig. D)

•  Open the chuck as far as possible.

•  Remove the chuck retaining screw,

located in the chuck, by turning it

clockwise using a screwdriver.

•  Tighten an Allen key into the chuck and

strike it with a hammer as shown.

•  Remove the Allen key.

•  Remove the chuck by turning it

counterclockwise.

•  To refit the chuck, screw it onto the

spindle and secure it with the chuck

retaining screw.

Use

Warning!

 Let the tool work at its own pace.

Do not overload.

Warning!

 Before drilling into walls, floors or

ceilings, check for the location of wiring and

pipes.

Selecting the direction of rotation

(Fig. E)

For drilling and for tightening screws, use

forward (clockwise) rotation. For loosening

screws or removing a jammed drill bit, use

reverse (counterclockwise) rotation.

•  To select forward rotation, push the

forward/reverse slider (3) to the centre

position.
