18

19

 BSB18SBL

................................4779 80 01...

   ...000001-999999

..................................... 13 mm

..................................... 13 mm

..................................... 40 mm

....................................... 6 mm

.......................... 450/1700 min

-1

.................... 7200 / 26000 min

-1

..................................... 65 Nm

..................................... 18 V

.................................. 2-13 mm

.......................... 1,4 ... 2,2 kg

.................................-18...+50 °C

........................... L18...R, L18...RHD

...................... AL18G, BLK1218, BL18S

..................................... 91 dB (A)

................................... 102 dB (A)

.................................. 10,5 m/s

2

.................................... 1,5 m/s

2

.................................... 1,9 m/s

2

.................................... 1,5 m/s

2

ENGLISH

TECHNICAL DATA

CORDLESS PERCUSSION DRILL/DRIVER

Production code ......................................................................................................................
Drilling capacity in steel ..........................................................................................................

Drilling capacity in brick and tile .............................................................................................

Drilling capacity in wood .........................................................................................................

Wood screws (without pre-drilling) .........................................................................................

No-load speed, 1st gear / 2nd gear .......................................................................................

Impact rate, 1st gear / 2nd gear .............................................................................................

Torque max  ............................................................................................................................

Battery voltage ........................................................................................................................

Drill chuck range .....................................................................................................................

Weight according EPTA-Procedure 01/2014 (1.5 Ah ... 9.0 Ah) ...........................................

Recommended ambient operating temperature ...................................................................

Recommended battery types .................................................................................................

Recommended charger..........................................................................................................

Noise/vibration information

Measured values determined according to EN 62841.

Typically, the A-weighted noise levels of the tool are:

  Sound pressure level (Uncertainty K=5dB(A)) ..................................................................

  Sound power level (Uncertainty K=5dB(A)) ......................................................................

Always wear ear protectors!

Total vibration values (vector sum in the three axes) determined according to EN 62841.

Vibration emission value a

h

  Impact drilling into concrete ...............................................................................................

  Uncertainty K= ....................................................................................................................

  Drilling into metal ................................................................................................................

  Uncertainty K= ....................................................................................................................

 WARNING  Read all safety warnings, instructions, illustrations and

specifications provided with this power tool.

 Failure to follow all instructions listed

below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

 DRILL SAFETY WARNINGS

Safety instructions for all operations

Hold the power tool by insulated gripping surfaces, when performing an operation

where the cutting accessory or fasteners may contact hidden wiring.

Cutting accessory or fasteners contacting a “live” wire may make exposed metal parts of

the power tool “live” and could give the operator an electric shock.

Wear ear protectors when impact drilling.

Exposure to noise can cause hearing loss.

Safety instructions when using long drill bits

Never operate at higher speed than the maximum speed rated of the drill bit.

 At

higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the

workpiece, resulting the personal injury.

Always start drilling at low speed and with the bit tip in contact with the

workpiece.

At higher speeds, the bit is likely to bend if allowed to rotate freely without

contacting the workpiece, resulting the personal injury.

Apply pressure only in direct line with the bit and do not apply excessive

pressure.

Bits can bend causing breakage or loss of control, resulting in personal injury.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when working with the machine.

The use of protective clothing is recommended, such as dust mask, protective gloves,

sturdy non-slip footwear, helmet and ear defenders.

The dust produced when using this tool may be harmful to health. Do not inhale the dust.

Wear a suitable dust protection mask.

Do not machine any materials that present a danger to health (e.g. asbestos).

Switch the device off immediately if the insertion tool stalls! Do not switch the device on

again while the insertion tool is stalled, as doing so could trigger a sudden recoil with a

high reactive force. Determine why the insertion tool stalled and rectify this, paying heed

to the safety instructions.

The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.

The insertion tool may become hot during use.

WARNING!

Danger of burns

•  when changing tools

•  when setting the device down
Chips and splinters must not be removed while the machine is running.

When working in walls ceiling, or floor, take care to avoid electric cables and gas or

waterpipes.

Clamp your workpiece with a clamping device. Unclamped workpieces can cause severe

injury and damage.

Remove the battery pack before starting any work on the machine.

Do not dispose of used battery packs in the household refuse or by burning them. AEG

Distributors offer to retrieve old batteries to protect our environment.

Do not store the battery pack together with metal objects (short circuit risk).

Use only System GBS chargers for charging System GBS battery packs. Do not use

battery packs from other systems.

Never break open battery packs and chargers and store only in dry rooms. Keep dry at

all times.

Battery acid may leak from damaged batteries under extreme load or extreme

temperatures. In case of contact with battery acid wash it off immediately with soap and

water. In case of eye contact rinse thoroughly for at least 10 minutes and immediately

seek medical attention.

Warning!

To reduce the risk of fire, personal injury, and product damage due to a short

circuit, never immerse your tool, battery pack or charger in fluid or allow a fluid to flow

WARNING

The vibration and noise emission level given in this information sheet has been measured in accordance with a standardized test given in EN 62841 and may be used to compare one

tool with another. It may be used for a preliminary assessment of exposure.

The declared vibration and noise emission level represents the main applications of the tool. However if the tool is used for different applications, with different accessories or poorly

maintained, the vibration and noise emission may differ. This may significantly increase the exposure level over the total working period.

An estimation of the level of exposure to vibration and noise should also take into account the times when the tool is switched off or when it is running but not actually doing the job. This

may significantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the effects of vibration and/or noise such as: maintain the tool and the accessories, keep the hands warm, organization of

work patterns.

ENGLISH

inside them. Corrosive or conductive fluids, such as seawater, certain industrial

chemicals, and bleach or bleach containing products, etc., can cause a short circuit.

SPECIFIED CONDITIONS OF USE

The battery drill/screwdriver may be used for drilling and screwdriving for independent

use away from mains supply.

Do not use this product in any other way as stated for normal use.

EC-DECLARATION OF CONFORMITY

We declare as the manufacturer under our sole responsibility that the product described

under “Technical Data” fulfills all the relevant regulations and the directives 2011/65/EU

(RoHS), 2014/30/EU, 2006/42/EC, and the following harmonized standards have been

used:

EN 62841-1:2015

EN 62841-2-1:2018+A11:2019

EN 55014-1:2017+A11:2020

EN 55014-2:2015

EN IEC 63000:2018

Winnenden, 2020-09-18

Alexander Krug

Managing Director

Authorized to compile the technical file

Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

GB-DECLARATION OF CONFORMITY

We declare as the manufacturer under our sole responsibility that the product described

under “Technical Data” fulfills all the relevant provisions of the following Regulations S.I.

2008/1597 (as amended), S.I. 2016/1091 (as amended), S.I. 2012/3032 (as amended)

and  that the following designated standards have been used:

BS EN 62841-1:2015

BS EN 62841-2-1:2018+A11:2019

BS EN 55014-1:2017+A11:2020

BS EN 55014-2:2015

BS EN IEC 63000:2018

Winnenden, 2020-09-18

Alexander Krug

Managing Director

Authorized to compile the technical file.

Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

BATTERIES

Battery packs which have not been used for some time should be recharged before use.

Temperatures in excess of 50°C (122°F) reduce the performance of the battery pack.

Avoid extended exposure to heat or sunshine (risk of overheating).

The contacts of chargers and battery packs must be kept clean.

For an optimum life-time, the battery packs have to be fully charged, after used.

To obtain the longest possible battery life remove the battery pack from the charger once

it is fully charged.

For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C and away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

TRANSPORTING LITHIUM BATTERIES

Lithium-ion batteries are subject to the Dangerous Goods Legislation requirements.

Transportation of those batteries has to be done in accordance with local, national and

international provisions and regulations.
•  The user can transport the batteries by road without further requirements.

•  Commercial transport of Lithium-Ion batteries by third parties is subject to Dangerous

Goods regulations. Transport preparation and transport are exclusively to be carried

out by appropriately trained persons and the process has to be accompanied by

corresponding experts.

When transporting batteries:
•  Ensure that battery contact terminals are protected and insulated to prevent short

circuit.

•  Ensure that battery pack is secured against movement within packaging.

•  Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

BATTERY PACK PROTECTION

The battery pack has overload protection that protects it from being overloaded and

helps to ensure long life.

Under extreme stress the battery electronics switch off the machine automatically. To

restart, switch the machine off and then on again. If the machine does not start up again,

the battery pack may have discharged completely. In this case it must be recharged in

the battery charger.

MAINTENANCE

Use only AEG accessories and spare parts. Should components need to be replaced

which have not been described, please contact one of our AEG service agents (see our

list of guarantee/service addresses).

If needed, an exploded view of the tool can be ordered. Please state the machine type

printed as well as the six-digit No. on the label and order the drawing at your local service

agents or directly at: Techtronic Industries GmbH, Max-Eyth-Straße 10,

71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any work on the

machine.

Please read the instructions carefully before starting the

machine.

Do not dispose electric tools, batteries/rechargeable batteries

together with household waste material.

Electric tools and batteries that have reached the end of their life

must be collected separately and returned to an environmentally

compatible recycling facility.

Check with your local authority or retailer for recycling advice

and collection point.

n

0

No-load speed

V

Volts
Direct current
European Conformity Mark

British Confomity Mark

Ukraine Conformity Mark

EurAsian Conformity Mark
