Шуруповерты AEG BE 750 R 4935449160 - инструкция пользователя по применению, эксплуатации и установке на русском языке. Мы надеемся, она поможет вам решить возникшие у вас вопросы при эксплуатации техники.
Если остались вопросы, задайте их в комментариях после инструкции.
"Загружаем инструкцию", означает, что нужно подождать пока файл загрузится и можно будет его читать онлайн. Некоторые инструкции очень большие и время их появления зависит от вашей скорости интернета.
21
20
SBE 750 RZ
SBE 750 RE
SBE 750 RES
....4428 41 01... ............................4428 51 01... .....................4497 83 01...
....4494 96 01...
...000001-999999 .................. ...000001-999999 ............. ...000001-999999
.......750 W ...........................750 W ...................... 750 W
.......375 W ...........................375 W ...................... 375 W
. 0-3000 min
-1
................. 0-3000 min
-1
............. 0-3000 min
-1
.....1450 min
-1
.....................1450 min
-1
................ 1450 min
-1
...23200 min
-1
...................23200 min
-1
.............. 23200 min
-1
.........27 Nm ...........................27 Nm ...................... 27 Nm
.........16 mm ...........................16 mm ..................... 16 mm
.........20 mm ...........................20 mm ..................... 20 mm
.........13 mm ...........................13 mm ..................... 13 mm
.........30 mm ...........................30 mm ..................... 30 mm
.. 1,5-13 mm .................... 1,5-13 mm ............... 1,5-13 mm
.1/2"x20 ........................ 1/2"x20 ................... 1/2"x20
.........43 mm ...........................43 mm ..................... 43 mm
......1,95 kg ..........................1,95 kg .................... 1,95 kg
......81,5 dB (A)....................81,5 dB (A) .............. 81,5 dB (A)
......92,5 dB (A)....................92,5 dB (A) .............. 92,5 dB (A)
.........89 dB (A).......................89 dB (A) ................. 89 dB (A)
.......100 dB (A).....................100 dB (A) ............... 100 dB (A)
........3,4 m/s
2
.........................3,4 m/s
2
................... 3,4 m/s
2
........1,5 m/s
2
.........................1,5 m/s
2
................... 1,5 m/s
2
......20,2 m/s
2
.......................20,2 m/s
2
................. 20,2 m/s
2
........1,5 m/s
2
.........................1,5 m/s
2
................... 1,5 m/s
2
........2,5 m/s
2
.........................2,5 m/s
2
................... 2,5 m/s
2
........1,5 m/s
2
.........................1,5 m/s
2
................... 1,5 m/s
2
BE 750 R
SBE 705 RE
SBE 705 RZ
....4491 61 01... ............................4428 31 01... .....................4494 91 01...
..........................................................4494 96 01...
...000001-999999 .................. ...000001-999999 ............. ...000001-999999
.......750 W ...........................705 W ...................... 705 W
.......375 W ...........................350 W ...................... 350 W
. 0-3000 min
-1
................. 0-2800 min
-1
............. 0-2800 min
-1
.....1450 min
-1
.....................1600 min
-1
................ 1600 min
-1
........... - min
-1
...................25600 min
-1
.............. 25600 min
-1
.........27 Nm ...........................25 Nm ...................... 25 Nm
........... - .................................15 mm ..................... 15 mm
........... - .................................20 mm ..................... 20 mm
.........13 mm ...........................13 mm ..................... 13 mm
.........30 mm ...........................30 mm ..................... 30 mm
.. 1,5-13 mm .................... 1,5-13 mm ............... 1,5-13 mm
.1/2"x20 ........................ 1/2"x20 ................... 1/2"x20
.........43 mm ...........................43 mm ..................... 43 mm
......1,95 kg ..........................1,95 kg .................... 1,95 kg
......81,5 dB (A)....................81,5 dB (A) .............. 81,5 dB (A)
......92,5 dB (A)....................92,5 dB (A) .............. 92,5 dB (A)
........... - .................................89 dB (A) ................. 89 dB (A)
........... - ...............................100 dB (A) ............... 100 dB (A)
........3,4 m/s2 ........................3,4 m/s
2
................... 3,4 m/s
2
........1,5 m/s2 ........................1,5 m/s
2
................... 1,5 m/s
2
........... - ..............................20,2 m/s
2
................. 20,2 m/s
2
........... - ................................1,5 m/s
2
................... 1,5 m/s
2
........2,5 m/s2 ........................2,5 m/s
2
................... 2,5 m/s
2
........1,5 m/s2 ........................1,5 m/s
2
................... 1,5 m/s
2
ENGLISH
WARNING
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool
with another. It may be used for a preliminary assessment of
exposure.
The declared vibration emission level represents the main
applications of the tool. However if the tool is used for
different applications, with different accessories or poorly
maintained, the vibration emission may differ. This may
signifi cantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job. This
may signifi cantly reduce the exposure level over the total
working period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and
the accessories, keep the hands warm, organisation of work
patterns.
WARNING! Read all safety warnings and all
instructions.
Failure to follow the warnings and instructions
may result in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
DRILL / PERCUSSION DRILL SAFETY WARNINGS
Wear ear protectors when impact drilling.
Exposure to
noise can cause hearing loss.
Use auxiliary handle(s), if supplied with the tool.
Loss of
control can cause personal injury.
Hold the power tool by insulated gripping surfaces only,
when performing an operation where the cutting
accessory may contact hidden wiring or its own cord.
Cutting accessory contacting a "live" wire may make
exposed metal parts of the power tool "live" and could give
the operator an electric shock.
SCREWDRIVER SAFETY WARNINGS
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord.
Fasteners
contacting a "live" wire may make exposed metal parts of
the power tool "live" and could give the operator an electric
shock.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Use protective equipment. Always wear safety glasses when
working with the machine. The use of protective clothing is
recommended, such as dust mask, protective gloves, sturdy
non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to
health. Do not inhale the dust. Wear a suitable dust
protection mask.
Do not machine any materials that present a danger to
health (e.g. asbestos).
Switch the device off immediately if the insertion tool stalls!
Do not switch the device on again while the insertion tool is
stalled, as doing so could trigger a sudden recoil with a high
reactive force. Determine why the insertion tool stalled and
rectify this, paying heed to the safety instructions.
The possible causes may be:
• it is tilted in the workpiece to be machined
• it has pierced through the material to be machined
• the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.
WARNING!
Danger of burns
• when changing tools
• when setting the device down
Chips and splinters must not be removed while the machine
is running.
Keep mains lead clear from working range of the machine.
Always lead the cable away behind you.
When working in walls ceiling, or fl oor, take care to avoid
electric cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped
workpieces can cause severe injury and damage.
Always disconnect the plug from the socket before carrying
out any work on the machine.
When working with large drill diameters, the auxiliary handle
must be fastened in a right angle with the main handle (see
illustrations, section "Twisting the handle").
SPECIFIED CONDITIONS OF USE
The electronic percussion drill/screwdriver can be
universally used for drilling, percussion drilling, screwdriving
and cutting screw threads.
Do not use this product in any other way as stated for
normal use.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that the product
described under “Technical Data” fulfi lls all the relevant
provisions of the directives 2011/65/EU (RoHs), 2004/108/
EC, 2006/42/EC and the following harmonized standards
have been used:
EN 60745-1:2009 + A11:2010
EN 60745-2-1:2010
EN 60745-2-2:2010
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
EN 61000-3-2:2006 + A1:2009 + A2:2009
EN 61000-3-3:2013
EN 50581:2012
Winnenden, 2014-01-07
Alexander Krug
Managing Director
Authorized to compile the technical fi le
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
ENGLISH
TECHNICAL DATA
Production code.......................................................................................
.............................................................................................................
Rated input ..............................................................................................
Output ......................................................................................................
No-load speed .........................................................................................
Speed under load max ............................................................................
Rate of percussion under load max. ........................................................
Static jamming moment *.........................................................................
Drilling capacity in concrete .....................................................................
Drilling capacity in brick and tile ..............................................................
Drilling capacity in steel ...........................................................................
Drilling capacity in wood ..........................................................................
Drill chuck range ......................................................................................
Drive shank..............................................................................................
Chuck neck diameter ...............................................................................
Weight according EPTA-Procedure 01/2003 ...........................................
* Measured according to AEG norm N 877318
Noise information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
As drill/screwdriver
Sound pressure level (Uncertainty K=3dB(A)) .....................................
Sound power level (Uncertainty K=3dB(A)) .........................................
As impact drill
Sound pressure level (Uncertainty K=3dB(A)) .....................................
Sound power level (Uncertainty K=3dB(A)) .........................................
Wear ear protectors!
Vibration information
Vibration total values (triaxial vector sum) determined according to EN 60745
Drilling into metal
Vibration emission value a
h,DS
...............................................................
Uncertainty K= ......................................................................................
Impact drilling into concrete
Vibration emission value a
h,ID
................................................................
Uncertainty K= ......................................................................................
Screwing
Vibration emission value a
h
..................................................................
Uncertainty K= ......................................................................................
TECHNICAL DATA
Production code.......................................................................................
.............................................................................................................
Rated input ..............................................................................................
Output ......................................................................................................
No-load speed .........................................................................................
Speed under load max ............................................................................
Rate of percussion under load max. ........................................................
Static jamming moment *.........................................................................
Drilling capacity in concrete .....................................................................
Drilling capacity in brick and tile ..............................................................
Drilling capacity in steel ...........................................................................
Drilling capacity in wood ..........................................................................
Drill chuck range ......................................................................................
Drive shank..............................................................................................
Chuck neck diameter ...............................................................................
Weight according EPTA-Procedure 01/2003 ...........................................
* Measured according to AEG norm N 877318
Noise information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
As drill/screwdriver
Sound pressure level (Uncertainty K=3dB(A)) .....................................
Sound power level (Uncertainty K=3dB(A)) .........................................
As impact drill
Sound pressure level (Uncertainty K=3dB(A)) .....................................
Sound power level (Uncertainty K=3dB(A)) .........................................
Wear ear protectors!
Vibration information
Vibration total values (triaxial vector sum) determined according to EN 60745
Drilling into metal
Vibration emission value a
h,DS
...............................................................
Uncertainty K= ......................................................................................
Impact drilling into concrete
Vibration emission value a
h,ID
................................................................
Uncertainty K= ......................................................................................
Screwing
Vibration emission value a
h
..................................................................
Uncertainty K= ......................................................................................
