7

ENGLISH

1

1. Abrasive disc

To install the abrasive disc or the hook-and-loop type

pad (optional accessory), first remove all dirt and for

-

eign matter from the pad.

Then attach the abrasive disc to the pad, using the

hook-and-loop system of the abrasive disc and the pad.

Be careful to align the holes in the abrasive disc with

those in the pad.

To remove the disc from the pad, just pull up from its

edge.

Changing pad

CAUTION:

Make sure the new pad is installed

securely.

 Otherwise the pad may come off from the

tool and cause personal injury.

2

1

3

1. Random orbit with forced rotation mode    2. Shaft

lock button    3. Pad

Makita offers an extensive range of optional super soft,

soft and hard pads.

To change the pad, perform as follows:
1.

Use the change knob and change the mode into

random orbit with forced rotation mode.

2.

Press and hold the shaft lock button, and remove

the pad by turning the pad counterclockwise.

3.

Keep holding the shaft lock button, and install a

new pad by turning the pad clockwise firmly.

Dust nozzle

CAUTION:

Make sure the bolt is securely

tightened after installing the dust nozzle.

Otherwise the dust nozzle may fall and cause per-

sonal injury.

NOTICE:

Do not carry the tool by the dust noz-

zle.

 Otherwise the tool may be damaged.

You can remove the dust nozzle in accordance with the

operation.

To remove the dust nozzle, loosen the bolt, slightly open

the holder part, and remove the dust nozzle.

To install the dust nozzle, insert the mouth of the dust

nozzle into the dust outlet of the housing, align the

tongue of the holder part with the groove of the housing,

and tighten the bolt.

2

1

3

1. Dust nozzle    2. Dust outlet   3. Mouth

1

2

1. Holder part    2. Bolt

Dust collection (optional accessory)

1

3

2

1. Front cuffs 24   2. Hose   3. Dust outlet

If a Makita hose is used, you can connect the front cuffs

24 to the dust outlet directly.
