7

Installing or removing depressed center
grinding wheel/Multi-disc (accessory)

Fig.9

Mount the inner flange onto the spindle. Fit the
wheel/disc on the inner flange and screw the lock nut
onto the spindle.
To tighten the lock nut, press the shaft lock firmly so that
the spindle cannot revolve, then use the lock nut wrench
and securely tighten clockwise.

Fig.10

To remove the wheel, follow the installation procedure in
reverse.

Installing or removing diamond wheel
(optional accessory)

CAUTION:

•

Make sure that the arrow on the tool should point in
the same direction as the arrow on the diamond
wheel.

Fig.11
Fig.12

Mount the inner flange onto the spindle. Fit the diamond
wheel on over the inner flange and screw the lock nut
onto the spindle. Notice that flat side of the lock nut
should face the diamond wheel in case the diamond
wheel is used.

Installing or removing dust cover attachment
(Optional accessory)

WARNING:

•

Always be sure that the tool is switched off and
unplugged before installing or removing the dust
cover attachment. Failure to do so causes damage
to the tool or a personal injury.

There are three types of dust cover attachment and
each is used in one of different positions.

Fig.13
Fig.14
Fig.15

Place the dust cover attachment so that the side of the
dust cover attachment with the marking (A,B or C) faces
towards the tool head. Snap the pins of the dust cover
attachment in the vent.

Fig.16

Dust cover attachment can be removed by hand.

NOTE:

•

Clean out the dust cover attachment when it is
clogged with dust or foreign matters. Continuing
operation with a clogged dust cover attachment will
damage the tool.

OPERATION

WARNING:

•

It should never be necessary to force the tool. The
weight of the tool applies adequate pressure.
Forcing and excessive pressure could cause
dangerous wheel breakage.

•

ALWAYS replace wheel if tool is dropped while
grinding.

•

NEVER bang or hit grinding disc or wheel onto
work.

•

Avoid bouncing and snagging the wheel, especially
when working corners, sharp edges etc. This can
cause loss of control and kickback.

•

NEVER use tool with wood cutting blades and
other sawblades. Such blades when used on a
grinder frequently kick and cause loss of control
leading to personal injury.

CAUTION:

•

After operation, always switch off the tool and wait
until the wheel has come to a complete stop before
putting the tool down.

Grinding and sanding operation

ALWAYS hold the tool firmly with one hand on housing
and the other on the side handle. Turn the tool on and
then apply the wheel or disc to the workpiece.
In general, keep the edge of the wheel or disc at an
angle of about 15 degrees to the workpiece surface.
During the break-in period with a new wheel, do not work
the grinder in the B direction or it will cut into the
workpiece. Once the edge of the wheel has been
rounded off by use, the wheel may be worked in both A
and B direction.

Fig.17

Operation with diamond wheel (accessory )

WARNING:

•

Forcing and exerting excessive pressure or
allowing the wheel to bend, pinch or twist in the cut
can cause overheating of the motor and dangerous
kickback of the tool.

CAUTION:

•

After cutting operation, make sure that the
diamond wheel stops revolving completely. Then,
place the tool. It is dangerous to place the tool
before turning off the tool. If there are dust or dirt
around the tool, the tool may suck in them.

Be sure that the wheel does not contact the workpiece.
Turn the tool on and hold the tool firmly. Wait until the
wheel attains full speed. Now simply move the tool
forward over the workpiece surface, keeping it flat and
advancing smoothly until the cutting is completed.
