Explanation of general view
1-1. Shaft lock
2-1. Slide switch
3-1. Speed adjusting dial
5-1. Wheel guard
5-2. Bearing box
5-3. Screw
6-1. Wheel guard
6-2. Bearing box
6-3. Screw
7-1. Wheel guard
7-2. Bearing box
7-3. Screw
7-4. Lever
8-1. Screw
9-1. Lock nut
9-2. Depressed center grinding
wheel/Multi-disc
9-3. Inner flange
10-1. Lock nut wrench
10-2. Shaft lock
11-1. Lock nut
11-2. Diamond wheel
11-3. Inner flange
11-4. Spindle
12-1. Lock nut
12-2. Diamond wheel
12-3. Inner flange
12-4. Spindle
13-1. Marking A
14-1. Marking B
15-1. Marking C
16-1. Pin
16-2. Vent
18-1. Exhaust vent
18-2. Inhalation vent
SPECIFICATIONS
100 mm M10
-
9563C
-
9563CV
115 mm M14
9561CH
9564C
9561CVH
9564CV
Depressed center wheel diameter
Spindle thread
125 mm M14
9562CH
9565C
9562CVH
9565CV
No load speed (min
-1
)
11,000
11,000
2,800 - 11,000
2,800 - 11,000
Overall length
289 mm
299 mm
289 mm
299 mm
Net weight
1.8 kg
1.8 kg
1.8 kg
1.8 kg
Safety class
/II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Note: Specifications may differ from country to country.
END202-2
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･
Read instruction manual.
･
DOUBLE
INSULATION
･
Wear
safety
glasses.
･
Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of European Directive
2002/96/EC on waste electric and
electronic equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
ENE048-1
Intended use
The tool is intended for grinding, sanding and cutting of
metal and stone materials without the use of water.
ENF002-1
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.
For Model 9561CH/9561CVH/9562CH/9562CVH
ENG019-1
For European countries only
Noise and Vibration
The typical A-weighted sound pressure level is 83 dB (A).
The noise level under working may exceed 85 dB (A).
Wear ear protection.
The typical weighted root mean square acceleration
value is not more than 2.5 m/s
2
.
These values have been obtained according to
EN50144.
For Model
9563C/9563CV/9564C/9564CV/9565C/9565CV
ENG020-1
For European countries only
Noise and Vibration
The typical A-weighted sound pressure level is 83 dB (A).
The noise level under working may exceed 85 dB (A).
Wear ear protection.
The typical weighted root mean square acceleration
value is 5 m/s
2
.
These values have been obtained according to
EN50144.
ENH001-6
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this
