Before You Begin

SONOS by Sonance In-Wall and In-Ceiling speaker grilles
completely cover the exposed speaker frame, so only the grilles
(not the speakers themselves) require painting.

IMPORTANT: IF THE WALL OR CEILING WILL BE PAINTED AFTER THE SPEAKERS ARE INSTALLED, THE
SPEAKER FLANGE AND BAFFLE MUST BE MASKED BEFORE PAINTING THE WALL OR CEILING.

      Figure 8

Grille Painting Instructions

Preparing The Grille For Painting

Carefully remove the scrim cloth from the underside of the grille.
The scrim cloth is held in place with a light tacking glue. Use a
heating agent such as a heat gun or hair dryer to soften the glue
and carefully remove the cloth, since you will need to replace it
when you’re done painting the grille. Be careful not to deform

to properly replace the cloth on the grille. Remove any adhesive
residue from the back of the grille before beginning painting

Painting The Grille

1. Prime the grille with a metal primer/bonder in a spray can.
  Carefully follow the manufacturer’s directions on the can.

2. We recommend using water-based latex paint on the grilles.
  Thin the paint with a proper thinning agent to a ratio of 1:1
  paint-to-thinner, and strain it through a standard mesh strainer
  to remove any lumps.

IMPORTANT: DUE TO ITS INCREASED DURABILITY, OIL-BASED PAINT SHOULD BE CONSIDERED FOR VP
EXTREME SERIES SPEAKERS THAT ARE INSTALLED OUTDOORS.

3. Use a small touch-up gun or cap-spray gun with a #3 tip
  for painting.

  (A) Set the nozzle with a medium to wide fan

  (B) Set the pressure regulator to 60psi

  (C) Lightly spray the front of the grille in 3 quick strokes
       from approximately 10 inches away

  (D) Let the paint set for a minute, then turn the grille 90º
       and lightly spray the grille again in 3 quick strokes.
       Repeat this step until all four sides of the grille have
       been evenly painted evenly.

4. While the paint is still wet, inspect the grille and make
  sure that excess paint has not collected underneath the grille
  frame, and that none of the grille perforations ar

e filled with

  paint. If any are, use compressed air to blow the paint out of
  the perforations.

IMPORTANT: IF YOU FIND ANY GRILLE PERFORATIONS THAT ARE PLUGGED WITH PAINT AFTER THE PAINT
HAS DRIED, USE A STRAIGHT PIN OR SEWING NEEDLE TO CAREFULLY REMOVE THE PAINT.

5. Once the paint has thoroughly dried, replace the scrim cloth
  on the back of the grille and mount the grille on the speaker.
