11

Cordless Li-Ion handy saw

EN

OPERATING INSTRUCTIONS

NOTE:

Before using the tool, read the

instruction book carefully.

INTENDED USE:

The machine is intended for sawing wood,
plastic, soft metal and building materials while
resting firmly on the workpiece.

ASSEMBLY

REPLACING/INSERTING THE SAW BLADE

Remove the battery pack from the

socket before carrying out any

adjustment, servicing or maintenance.

When mounting the saw blade, wear

protective gloves.

 Danger of injury when

touching the saw blade. When changing the
saw blade, take care that the saw blade holder
is free of material residue, e. g. wood or metal
shavings.

1. SELECTING A SAW BLADE (See Fig. A)

NOTE:

 Only use maximum blade lengths

specified in table below for the intended
purpose of application. Failure to adhere
to this advice will result in damage to the
product and void of warranty.

Typical application

Pruning blade (152mm,

6TPI, 65Mn)

Garden limbs, etc.

Bi metal blade

(152mm, 18TPI, HSS)

Metals and wood

,etc.

2. INSERTING A SAW BLADE (See Fig. B)

Remove the battery pack from the

socket before carrying out any

adjustment, servicing or maintenance.

Pull down the tool-free blade clamp lever (6),
Insert the blade shank into the blade holder
until it stops. Release the clamp lever (6) to
lock the blade (7/8) in position.

Check the tight seating of the saw blade.

A loose saw blade can fall out and lead to
injuries.

3. REMOVING A SAW BLADE (See Fig. B)

To remove a blade, depress the clamp lever,
pull out the blade.

CHARGING

WARNING: The charger and battery

pack are specially designed to work

together so do not attempt to use any

other devices. Never insert or allow

metallic objects into your charger or

battery pack connections because of an

electrical failure and hazard will occur.

Your battery pack is UNCHARGED and you
must charge once before use
The battery charger supplied is matched to the
Li-Ion battery installed in the machine. Do not
use another battery charger.

1. CHARGING YOUR BATTERY PACK

The Li-Ion battery is protected against deep
discharging. When the battery is empty,
the machine is switched off by means of a
protective circuit. In a warm environment or
after heavy use, the battery pack may become
too hot to permit charging. Allow time for the
battery to cool down before recharging.

2. TO REMOVE OR INSTALL BATTERY

PACK (See Fig. C)

Depress the battery pack release button to
release and slide the battery pack out from
your tool. After recharge, slide it back into your
tool. A simple push and slight pressure will be
sufficient.

OPERATION

1. SAFETY ON/OFF SWITCH (See Fig. D)

Your switch is locked off to prevent accidental
starting. Depress the lock-off button (1) then
the on/off switch (5) and release lock-off button
(1). Your switch is now on. To switch off just
release the on/off switch.

2. WORKING INSTRUCTIONS

NOTE:

 Hold the machine away from yourself.

Stand in a secure and stable position.

WARNING: Always clamp and

support workpiece securely. Do

not touch blade to workpiece until saw
