8

!  ensure that the front end of the blade extends

through footplate E for the entire stroke length

•  Removing saw blade

9

-  press blade clamp D forward and hold it in that

position

-  pull out blade

-  release blade clamp D

•  Adjustable footplate

0

-  footplate E tilts in order to keep as much of its surface

in contact with the workpiece

-  adjust footplate by holding the saw firmly and turning

footplate to desired position

•  Blade storage compartment

!

-  ensure that storage compartment F is closed to

prevent blades from falling out

•  Operating the tool

!  securely clamp the workpiece

-  mark the cutting line on the workpiece

-  select desired sawing speed with wheel C

2

-  connect plug to power source (light B turns on

indicating that the tool is receiving power)

@

-  hold the tool with one hand on handle G

2

 and the

other on the insulated barrel grip H

2

-  switch on the tool

!  the tool should run at full speed before the blade

enters the workpiece

-  guide the tool along the marked cutting line

-  keep footplate E

2

 firmly against the workpiece to

minimize counter-force and vibration

•  Holding and guiding the tool

!  while working, always hold the tool at the

grey-coloured grip area(s)

#

-  keep ventilation slots J

2

 uncovered

-  do not apply too much pressure on the tool; let the tool

do the work for you

!  ensure that the saw blade extends beyond the

work throughout the stroke

$

•  Adjusting effective sawing depth

%

-  use both fastening bolts K for sliding footplate E

forward/backwards in order to enlarge/reduce the

effective sawing depth

!  do not attempt to adjust the effective stroke

length with screw l which is pre-set at

manufacturing

APPlICATION ADVICE

•  Plunge cutting

^

Plunge cuts can be made in wood and other soft

materials without pre-drilling a hole

-  use a thick saw blade

-  mount the blade with the teeth facing upward

-  hold the saw upside down as illustrated

-  mark desired cutting line on the workpiece

-  select position 1, 2 or 3 with wheel C

-  tilt the tool so that the blade does not touch the

workpiece

-  switch on the tool and carefully engage the moving

saw blade into the workpiece

-  after the blade has penetrated through the workpiece

continue sawing along the marked cutting line

!  do not make plunge cuts in metal materials

•  Use the appropriate saw blades

&

•  When cutting metals, lubricate saw blade regularly with

oil

•  Splinter-free cutting

-  cover cutting-line with several layers of wide tape

before cutting

-  always face the good side of the workpiece down

•  For more tips see www.skil.com

mAINTENANCE / SERVICE

•  This tool is not intended for professional use

•  Always keep tool and cord clean (especially ventilation

slots J

2

)

!  disconnect the plug before cleaning

•  If the tool should fail despite the care taken in

manufacturing and testing procedures, repair should be

carried out by an after-sales service centre for SKIL

power tools

-  send the tool

undismantled

 together with proof of

purchase to your dealer or the nearest SKIL service

station (addresses as well as the service diagram of

the tool are listed on www.skil.com)

ENVIRONmENT

•

Do not dispose of electric tools, accessories and

packaging together with household waste material

(only for EU countries)

-  in observance of European Directive 2012/19/EC on

waste of electric and electronic equipment and its

implementation in accordance with national law,

electric tools that have reached the end of their life

must be collected separately and returned to an

environmentally compatible recycling facility

- symbol

5

 will remind you of this when the need for

disposing occurs

DEClARATION OF CONFORmITY

Reciprocating saw 4900

Technical data

1

•  We declare under our sole responsibility that the product

described under “Technical data” is in conformity with the

following standards or standardization documents: EN

60745, EN 61000, EN 55014, in accordance with the

provisions of the directives 2004/108/EC (until

19.04.2016), 2014/30/EU (from 20.04.2016), 2006/42/

EC, 2011/65/EU

•

Technical file at

: SKIL Europe BV (PT-SEU/ENG1),

4825 BD Breda, NL

¹ÊÁÂÆιƼ½ÊÇǾ¼½Æ

ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿

ÍÊÇȽƓˁ˅ʿ˂ ʽ¼¹Ɠ

Ĺ¾ ÁÂÿʹ¹¾

ÈÈÊÇιĹƹ¿½Ê

12.03.2015
