ENGLISH

en

9

Use a suitable extraction unit.
Reduce dust exposure with the following measures:

- Do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits.

- Use an extraction unit and/or air purifiers.

- Ensure good ventilation of the workplace and

keep it clean using a vacuum cleaner. Sweeping

or blowing stirs up dust.

- Vacuum or wash protective clothing. Do not blow,

beat or brush.

See page 2.

1 Trigger  switch

2 Locking  button  for  continuous activation

3 Thumbwheel for setting the maximum stoke

rate *

4 Slide switch for setting the pendulum action *

5 Lever of the saw blade clamping fixture

6 LED  lights  *

7 Saw blade clamping fixture

8 Saw blade (shaft shape: universal shaft)*

9 Guide

10 Button for setting the guide

11 Front handle

12 Rear handle

* depending on equipment/not in scope of delivery

Before plugging in, check that the rated mains

voltage and mains frequency, as stated on the

type plate match your power supply.

Always install an RCD with a maximum trip

current of 30 mA upstream.

6.1 Fitting and removing the saw blade

Danger of injury due to the sharp saw blade.

After stopping work, the saw blade may still be

hot. Wear protective gloves.

Pull the mains plug out of the socket.

For access to the saw blade quick-clamping device

(2), adjust the guide (9) if required.

1 Fold the lever (5) of the saw blade clamping

fixture upwards and hold.

2 Insert the saw blade (8) until the stop or remove.

3 Release the lever (5).

4 Check that the saw blade is securely seated.

Note:

In case the saw blade ever brakes off and

cannot be removed by hand from the saw blade

clamping fixture: Fold the lever (5) of the saw blade

clamping fixture upwards and hold. Engage the tip

of a saw blade in the broken section and pull it out.

A fine-toothed metal saw blade is best suited for this

task.

6.2 Setting the guide

The cutting depth can be limited by shifting the

guide (9) (e.g. when sawing in front of a wall).
Occasionally shift the guide (9) to achieve even

wear of the saw blade.

1 Press the button (10) and shift the guide (9) to

the desired position.

2 Release the button (10) and shift the guide until

it engages.

Check the guide (9) to ensure that it is securely

fitted. It has to be engaged.

7.1 Set pendulum action (SSEP 1400 MVT)

The pendulum action of the saw blade increases the

sawing power (particularly in the case of soft

materials such as wood and plastics). Furthermore,

the pendulum motion reduces the stress applied to

the saw blade, as it is raised when emerging from

the workpiece.
Set the required pendulum motion using the

adjustment lever (4).
Recommended setting values:

0 =

  pendulum motion is deactivated.

for thin material, fine cuts, tight curves

1

 =  for hard materials (e.g. steel, chipboard)

2

 =  for thick materials (e.g. wood, plastic)

3

 =  maximum pendulum motion

for fast cuts (e.g. coniferous wood)

The best way to determine the ideal setting is

through a practical trial.

7.2 Setting maximum speed

(SSEP 1400 MVT)

Set the machine to maximum speed using the

setting wheel (3). This can also be done during

operation.
Recommended setting values:

Wood ....................................................... =

6

Light bricks ............................................... =

5 - 6

soft, unalloyed steel .................................. =

3 - 4

Aluminium................................................. =

3 - 5

Plastic ....................................................... =

1 - 4

Stainless steel .......................................... =

1 - 2

The best way to determine the ideal setting is

through a practical trial.

7.3 On/Off switch, continuous activation

Avoid inadvertent starts: always switch the

tool off when the plug is removed from the

mains socket or if there has been a power cut.

Switching on:

Press the trigger switch (1). The

stroke rate can be changed by pressing in the

trigger.

Switching off:

Release the trigger switch (1).

Continuous operation:

The trigger switch (1) can

be locked using the lock button (2) for continuous

operation. Press the trigger switch (1) again to stop

the machine.

In continuous operation, the machine

continues running if it is forced out of your

5. Overview

6. Assembly,

Initial Operation, Setting

7. Use
