ENGLISH

en

10

hands. Therefore always hold the machine with

both hands using the handle provided, stand

securely and concentrate.

7.4 Working Directions

Sawing:

Use a saw blade geared to the material to be sawn.
SSEP 1400 MVT: Set pendulum motion according

to the applications.
Adapt the stroke rate to the material to the sawn.

SSEP 1400 MVT: Set maximum stroke rate

according to the applications.
Press the machine with the guide (9) against the

workpiece. Switch on the machine, and only then

guide the saw blade against the workpiece.
Do not make contact with any objects or with the

ground with the moving saw blade (danger of

recoil!)
Avoid excessive pressure on the saw blade

(particularly in the case of long saw blades).
If the saw blade jams, turn the machine off

immediately. Widen the sawn gap slightly with a

suitable tool and take out the machine.
After completing the sawing cut, switch off the

machine and only take it out of the sawn gap to

place it down once the saw blade has come to a

standstill (danger of recoil).

Plunge cuts:

Plunge cuts may only be made in soft materials

such as wood or plastic. Only use short saw blades.
Hold the machine with both hands at the intended

handles, take a secure stance and concentrate on

the work.

Set the adjustment lever (4) to the "0" position

(pendulum motion is deactivated).

See illustration B, page 2:
The machine is pressed with the edge of the guide

(9) against the workpiece. The saw blade does not

make contact with the workpiece. Switch on the

machine. The corner of the guide serves as a pivot

point around which the machine is slowly aligned,

whereby the saw blade cuts into the workpiece.

7.5 Sawing close to the wall

Set the adjustment lever (4) to the "0" position

(pendulum motion is deactivated).

See illustration D, page 2.
When sawing near the wall, the saw blade can be

put into the saw blade clamping fixture with the

teeth pointing upwards (contrary to the normal

working position). Ensure that the pendulum action

is deactivated.

To saw tight curves: Use narrow saw blades.
Sawing metal: To increase the life of the saw

blades, apply cooling lubricant (cooling lubricant

rod 6.23443) along the cutting line.

On a regular basis, use compressed air to blow out

the machine through the rear ventilation slots.
Regularly clean the saw blade quick-clamping

fixture (2) and blow out with compressed air. Do not

oil or grease.

Use only genuine Metabo accessories.
Use only accessories which fulfil the requirements

and specifications listed in these operating

instructions.
See www.metabo.com or the catalogue for a

complete range of accessories.

Repairs to electrical tools must ONLY be

carried out by qualified electricians!

Contact your local Metabo representative if you

have Metabo power tools requiring repairs. See

www.metabo.com for addresses.
You can download a list of spare parts from

www.metabo.com.

Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.

Only for EU countries: Never dispose of

power tools in your household waste! Used

power tools must be collected separately and

handed in for environmentally compatible recycling

in accordance with European Directive 2002/96/EC

on waste electrical and electronic equipment and its

implementation in national legal systems.

Explanatory notes on the specifications on page 3.

Changes due to technological progress reserved.
P

1

= Rated  input  power

P

2

= Power output

I

= Current

n

0

= Stroke rate at idle speed

s

= Stroke  length

m

= Weight without mains cable

Measured values determined in conformity with

EN 60745.

Machine in protection class II

~

AC Power

The technical specifications quoted are subject to

tolerances (in compliance with the relevant valid

standards).

Emission values

These values make it possible to assess the

emissions from the power tool and to compare

different power tools. The actual load may be higher

8. Tips and Tricks

9. Maintenance

10. Accessories

11. Repairs

12. Environmental Protection

13. Technical Data
