9 ENGLISH

Pass the blade cap through the blade until the hook

catches the base cover. Note the direction of the blade

cap when attaching; the wider hook comes front side.

When removing the blade cap, lift it while pinching the

both sides.

►

Fig.15:

1.

 Blade cap

2.

 Hook

During operation, insert the blade cap to the hook on

the base as illustrated until it clicks.

►

Fig.16:

1.

 Blade cap

2.

 Hook

Hex wrench storage

When not in use, store the hex wrench as shown in the

figure to keep it from being lost.

►

Fig.17:

1.

 Hex wrench

Connecting a vacuum cleaner

Connect a Makita vacuum cleaner for clean operation.

Remove the rubber cap on the dust collector and con-

nect the vacuum cleaner's hose to the nozzle of the

dust collector.

►

Fig.18:

1.

 Dust collector

2.

 Rubber cap

3.

 Vacuum

cleaner hose

OPERATION

CAUTION:

Hold the tool firmly.

CAUTION:

Always hold the base flush with

the workpiece during cutting. Never perform a

curved cut.

Failure to do so may cause blade break-

age, resulting in a serious injury.

The V-notch and convexed portion in the base cover of

the tool indicate the position of the blade. Always check

the blade position when cutting.

The base cover of the tool

►

Fig.19:

1.

 V-notch

2.

 Convexed portion

3.

 Blade

NOTE:

 For accurate cutting, it is recommended to

draw cutting lines on the workpiece beforehand.

1.

  Place the tip of the blade on the start line. Tilt the

tool so that the front edge of the base touches the work-

piece. Align the bottom of the V-notch in the front edge

with the cutting line.

►

Fig.20

2.

Slowly pull the trigger without the blade making

any contact with the workpiece. When the blade attains

full speed, push the tool toward the workpiece. As the

blade pierces the workpiece, make the whole surface of

the base cover contact with the workpiece.

►

Fig.21

3.

Move the tool straight forward until the cutting

finishes.

MAINTENANCE

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before attempting to perform inspection or

maintenance.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

Cleaning the base cover

Clean off the cutting chips and dust accumlated on the

base cover. Lift the base cover while pulling the hook on

the back end to remove. Follow the removal procedure

in reverse when installing.

►

Fig.22:

1.

 Base cover

2.

 Hook

CAUTION:

Pay attention to the tip of the blade

and cutting chips when removing the base cover.

NOTICE:

 Perform the cleaning periodically. Dirty

base cover may damage or deface the working

surface.

To maintain product SAFETY and RELIABILITY,

repairs, any other maintenance or adjustment should

be performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.

OPTIONAL

ACCESSORIES

CAUTION:

These accessories or attachments

are recommended for use with your Makita tool

specified in this manual.

 The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or attachment

for its stated purpose.

If you need any assistance for more details regard

-

ing these accessories, ask your local Makita Service

Center.

•

Drywall saw blade

•

Wood saw blade

•

Dust box

•

Dust collector

•

Hex wrench

•

Hook

•

Makita genuine battery and charger

NOTE:

 Some items in the list may be included in the

tool package as standard accessories. They may

differ from country to country.
