04

Chapter 2   Connect to the Internet

Chapter 2 

Connect to the Internet

2. 1.  Position Your Router

•

The  product  should  not  be  located  in  a  place  where  it  will  be  exposed  to  moisture  or
excessive heat.

•

Place the router in a location where it can be connected to multiple devices as well as to
a power source.

•

Make  sure  the  cables  and  power  cord  are  safely  placed  out  of  the  way  so  they  do  not
create a tripping hazard.

•

The router can be placed on a shelf or desktop.

•

Keep  the  router  away  from  devices  with  strong  electromagnetic  reference,  such  as
Bluetooth devices, cordless phones and microwaves.

Generally, the router is placed on a horizontal surface, such as on a shelf or desktop. The

device also can be mounted on the wall as shown in the following figure.

∅

D

L2

H

2.5

2.87

1.63

66

4.8

14

9.06

9.06

NOTE:

5.3mm<D<8.56mm

H<2.87mm;
L2>10.13mm

Note

:

The diameter of the screw, 5.3 mm<D<8.56 mm. The distance of two screws is 66 mm. The screw that project from the wall need
around 2.7 mm based, and the length of the screw need to be at least 10.13 mm to withstand the weight of the product.

2. 2.  Connect to the Internet

The  Router  provides  two  working  modes:

Router Mode

and

Access Point Mode

. You can

choose  the  mode  to  better  suit  your  network  needs  and  follow  the  guide  to  complete  the

configuration.
