- 18 -

12/2020

 Copyright © 2020, Fast ČR, a.s.

CENTRAL ROTARY BRUSH

 ■

Push on the latches

G2

 of the central rotary brush cover

G1

 and take the cover out

together with the brush.

 ■

Use a dry wiping cloth to clean out the compartment

G5

 in which the rotary brush

is housed. Also clean the suction hole, the procedure is described later in this

user's manual.

 ■

Remove any dirt and material (dust, wound on hair, animal fur, etc.) from the rotary

brush

G3

 and the bearings

G4

. You can cut heavily wound on hair using the blade

H2

 of the cleaning brush.

 ■

Reinsert the rotary brush and its cover.

Attention:

In the event that an excessive amount of dirty material

accumulates on the central rotary brush and in its compartment,

there is a  risk of permanently damaging the vacuum cleaner.

Regularly inspect the condition of the brush.

Do not use the vacuum cleaner without the central rotary brush.

 ■

When using the rubber rotary brush

G6

 instead of brush

A14

, proceed in the same

manner when cleaning it.

SUCTION HOLE

 ■

The suction hole is located underneath the central rotary brush, therefore, take it out

before cleaning the suction hole as described in the previous chapter. With repeat

use, dust and dirt may accumulate around the suction hole, which may manifest

itself through decreased suction efficiency. Remove the dirt and dust from the

suction hole using a soft brush. Regularly clean the suction hole to ensure maximum

suction power.

SIDE ROTARY BRUSH

 ■

Take out the rotary brush

A11

 by pulling it upwards. Remove any dust and dirt from

the location where the brush was mounted.

 ■

Remove all dust and dirt from the brush. If necessary you may wash the brush under

running water. If the bristles were deformed while the vacuum cleaner was running,

dip them in warm water to allow them to return to their original shape. Allow the

brush to dry before reattaching to the vacuum cleaner.

 ■

After cleaning it, reattach it.

Note:

The rotary brush wears out with use. After a certain time it is necessary to

replace the worn out brush with a new one. To order a new brush, contact

your vendor or an authorised service centre.

COMPLETE ROBOTIC VACUUM CLEANER

 ■

Regularly wipe the surface of the vacuum cleaner using a soft dry wiping cloth.

 ■

First remove any coarser dirty material from the front swivel wheel

A16

 and the

motorised wheels

A13

 and

A19

. Then clean them around their entire perimeter

using a lightly dampened cloth and wipe them dry. Do not forget to also clean the

area around the wheels.

 ■

At least once per week, or more often, wipe the sensors

A10

,

A12

,

A17

 on the

underside of the vacuum cleaner and the side sensor

A7

 using a  soft dry wiping

cloth or a cotton bud.

 ■

Regularly clean the vents

A8

 along both sides of the vacuum cleaner.

CHARGING STATION

 ■

At least once per week, clean the surface of the charging station

B2

 including the

charging contacts

B3

 using a soft dry wiping cloth.

STORAGE

When not using the vacuum cleaner for an extended period of time, do the following:

 ■

Hold down button

A5

 (

 ) to turn off the vacuum cleaner.

 ■

Clean the vacuum cleaner as described in chapter CLEANING AND MAINTENANCE.

 ■

Disconnect the charging station from the power socket.

 ■

Store the vacuum cleaner with all its accessories in a dry, clean and cool place.

TECHNICAL SPECIFICATIONS

Robotic vacuum cleaner

Dimensions (diameter × height) ................................................................................ 350 × 95 mm

Weight ................................................................................................................................................3.8 kg

Motor power output .......................................................................................................................80 W

Operating time per single charge ........................................................................... up to 200 min

Dust container capacity ............................................................................................................ 480 ml

Water tank capacity .....................................................................................................................260 ml

Capacity of dust container inside the water tank .............................................................240 ml

Vacuuming system..................................................................................SUPER CYCLONE 8 000 Pa

Navigation system ....................................................................................................Sencor Nav. 18.0

Power adapter

Input ...............................................................................................100-240 V~, 50-60 Hz, 0.9 A MAX

Output .................................................................................................................... 20.0 V, 1.8 A, 36.0 W

Battery

Type .............................................................................................................................  6,400 mAh Li-Ion

Charging time .................................................................................................................................. 4–6 h

Input ........................................................................................................................................16.6 V, 1.5 A

The declared noise emission level is lower than 69 dB(A), which represents a level A of

sound power with respect to a reference sound power of 1 pW.

DISPOSAL OF USED BATTERIES

 ■

Prior to handing over the product at a specialised collection facility, it is necessary

to ensure that the battery is removed. Prior to removing the battery, turn off the

vacuum cleaner using the main switch. Disconnect the battery according to the

procedure described in chapter REPLACING THE BATTERY.

This symbol indicates that used batteries do not belong in ordinary

municipal waste. Hand over used batteries to designated collection

points for proper disposal. Correct disposal of batteries will help

prevent negative impacts on the environment and human health.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of

used batteries, request the necessary information about the correct

disposal method from the local authorities or from your vendor.

INSTRUCTIONS AND INFORMATION REGARDING THE

DISPOSAL OF USED PACKAGING MATERIALS

Dispose of used packaging material at a site designated for waste in your municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC

EQUIPMENT

This symbol on products or original documents means that used

electric or electronic products must not be added to ordinary

municipal waste. For proper disposal, renewal and recycling, hand

these products over to determined collection points. Alternatively, in

some European Union states or other European countries you may

return your appliances to the local retailer when buying an equivalent

new appliance.

Correct disposal of this product helps save valuable natural resources

and prevents potential negative effects on the environment and human health, which

could result from improper waste disposal. Ask your local authorities or collection

facility for more details.

In accordance with national regulations penalties may be imposed for the incorrect

disposal of this type of waste.

For business entities in European Union states

If you want to dispose of electric or electronic devices, ask your retailer or supplier for

the necessary information.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of this product,

request the necessary information about the correct disposal method from the local

council or from your retailer.

This product meets all the basic requirements of EU directives related to

it.

SENCOR hereby declares that radio device model number SRV 9550BK is in compliance

with directive 2014/53/EU. The full wording of the EU Declaration of Conformity is

available at the website: www.sencor.eu.
