8

>1.5m

>0.5m

>0.5m

1. Remove the protective film

3. Place the charging dock on the level ground against wall

and connect to a power outlet

2. Install the side brush

Click

4. Place the robot onto the charging dock to recharge. The

robot will turn on automatically and charge

Preparation

Note:

•

Make sure there is a distance of 0.5 meters or more on either side of the charging dock, and

more than 1.5 meters in front of it.

•

Tidy up any loose cord which could accidentally move or unplug the charging dock.

•

To ensure you can well connect to the robot with your phone, make sure the robot and

charging dock are in the range of Wi-Fi.

•

Do not place the charging dock in an area with direct sunlight or where other objects could

block its signaling area, as this may hinder the robot from returning to the charging dock.

     Battery Level Indicator

•

White: Battery level is more than 15%

•

Orange: Battery level is less than 15%

Note:

•

Fully charge before first use.

•

Don't install the mopping module while charging. Ensure the charging is in a safe

environment to prevent floor damage caused by wet dishcloth.

Note:

 Install the side brush until it clicks into place.

Remove the protective films on the side of collision buffer and charging dock.
