EN

16

CHARGING

•

Connect the adaptor to the stick vacuum cleaner by the foreseen

connection on the back side of the appliance to charge the stick vacuum cleaner.

•

The battery charge indicator indicates when the appliance has been fully

charged.

•

The machine cannot be started during charging.

WALL MOUNT

Please follow below instructions to fix the wall mount:
1.

Drill 3 holes in the wall corresponding to the attachment points of the wall

mount.

2.

Insert the supplied plugs into the wall.

3.

Fix the wall mount using the supplied screws.

4.

To store the device, simply hang it on the wall mount.

WALL MOUNT

Please follow below instructions to fix the wall mount:

1.  Drill 3 holes in the wall corresponding to the attachment points of

the wall mount.

2.  Insert the supplied plugs into the wall.

3.  Fix the wall mount using the supplied screws.

4.  Slide the Wall Mount Holder into the hook on the back of the

cleaner handle

5.  To store the device, simply hang it on the wall mount.

USE

•  Press the on-off switch on the handle to turn the vacuum cleaner

on. The battery indicator light is blue and indicates the battery

level. If the battery is almost empty, the light will flash on and

switch off.

•  When you switch on the vacuum cleaner, the rotating floor brush

will begin to turn. This will cause the dirt in the opening to be

shifted and thereby vacuumed up.

•  Press the power control to switch between turbo and normal

modes.

•  Turbo brush is equipped with a safety which will ensure that it

shuts itself off if, for example, objects which are too large are

sucked up, or if fingers become tangled in the floor brush. This is

for personal safety and to protect the motor. To restart the floor

brush, press 2 times the on/off button or the power regulation

button.

USE

•

Press the on-off switch on the handle to turn the machine on. The battery

indicator light is blue and indicates the battery level. If the battery is almost

empty, the light will flash on and off.

•

When you switch on the machine, the rotating floor brush will begin to

turn. This will cause the dirt in the opening to be shifted and thereby vacuumed

up.

•

Press the power control to switch between turbo and normal modes.

•

Turbo brush is equipped with a safety which will ensure that it shuts itself

off if, for example, objects which are too large are sucked up, or if fingers become

tangled in the floor brush. This is for personal safety and to protect the motor. To

restart the floor brush, press 2 times the on/off button or the speed control.

CLEANING AND MAINTENANCE

CLEANING THE MACHINE
Clean the machine with a slightly moist soft cloth. Dry the machine off well. Never

submerge the machine in water!
CLEANING THE DUST RESERVOIR
1.

Press the dust reservoir unlock button to remove it from the vacuum cleaner.

2.

Then take the filters out of the dust reservoir. Empty the dust reservoir.

3.

Take part A (HEPA filter) from part B (Filter holder).

4.  Shake out the dirt from the HEPA filter, filter holder and dust reservoir.

The HEPA filter must not be washed!

The dust reservoir and filter holder can be washed under the tap, then dried

completely.

We advise replacing the filters regularly to ensure an optimal operation of the

machine. Dirty filters will reduce the suction power drastically. After every

cleaning, clean the dust reservoir and the filters to extend the life span of your

machine.
